Semi-conductor System Div
24mm SM Tape Feeder (Front, Rear) - Undefined
NO. PART NO. PART NAME TYPE REMARKQ'TY
74
J7265171A
PCB COVER
1 SM1-MF32-077
76
J7066316A STOPPER OUTTER PIN 1 SM1-MF32-014
78
J7066181A
T LEVER PIN
1 SMS1-MF32-016-03
79
J7065131A DAMPER 1 TF12-N226
80
J7066317A
DAMPER SHAFT
1 SM1-MF32-035
81
J7066315A DAMPER WASHER 1 SM1-MF32-034
82
J7066184A
PCB SUPPORT PIN
4 SM1-MF32-042
83
J7066237A SPROCKET SHAFT 24 SCREW 1 SM1-MF24-002-07
84
J6711249A
COUPLER PLUG
1 KS-4-M5-SA34268KR
85
J7066025A COUPLER BKT2 1 SM1-MF08-091
93
1301226
C RING
1 M12
94
C RING 1 M17
98
PLAIN WASHER
4 M3
101
J600530065 BUTTON HEAD CAP SCREW 12 M3*6
102
J6006300650
FLAT HEAD CAP SCREW
7 M3*6
105
BUTTON HEAD SOCKET SCREW 3 M4*8
107
BUTTON HEAD SOCKET SCREW
3 M4*15
108
J6005301550 BUTTON HEAD SOCKET SCREW 3 M3*15
109
BUTTON HEAD SOCKET SCREW
7 M3*10
110
THD SCREW 8 M3*10
112
FLAT HEAD CAP SCREW
6 M4*8
System Engineering Team
