3 Calibration Functions
NOTE
The heads and gantries must be referenced prior to the performance of the calibration functions.
For a complete calibration of the machine, the test program offers the possibility to start all calibration functions
from the "Calibrate entire machine" setting box with the aid of the
Calibrate machine...
functions (see section
3.2, Fig. 3.2.1).
However, it is also possible to start the calibration functions individually from the corresponding displays. The
functions for the placement stations SIPLACE 80S-20/S-23 must be performed on both
gantries.
A complete description of the performance of the individual calibration functions is contained in the respective
sections of this chapter.
To be able to correct also those constant placement offsets that, to some extent, still exist even after the calibration
has been carried out, the Test Program provides the capability to start from the setting box “Calibrate complete
machine” - using the
Fine calibration
function - the measuring program that is integrated into the Test Program.
The procedure to be followed for the fine calibration is described in chapt. 5 of these instructions.
3
3 Calibration Functions User Manual Test Program SITEST
Software Version 405.xx Issue 01/99
3 - 2
User Manual Test Program SITEST 3 Calibration Functions
Software Version 405.xx Issue 01/99 3.1 Preparation for the Performance of the Calibration Functions
3 - 3
3.1 Preparation for the Performance of the Calibration
Functions
● In the main view click on the
Overall reference run
button to have all gantry and head axes perform a
reference run.
● Make sure that nozzles are fitted to all (center) sleeves of the revolver heads, i.e.
nozzle type
756
to the 12-nozzle revolver head,
nozzle type
720
to the 6-nozzle revolver head
,
and a nozzle of the type
416
to the IC head of SIPLACE 80F
4
/80F
5
.
NOTE
When you perform the calibration of the machine, the gantry that is not currently required will auto-
matically be moved to the park position.
3
● Place the calibration tool into the "calibration piece pocket" (see Fig. 3.12.1).
NOTE
The calibration tool must be absolutely free of contamination and is to be placed into the "calibration tool
pocket" with the imprint of the fiducial structure facing down.
3
● In the main view select the desired gantry by clicking on the corresponding icon.
NOTE
If the calibration activities are performed using the
Calibrate machine...
function, a selection of the gantry
is not required.
3
