0 Introduction to the User Interface of the Test Program User Manual Test Program SITEST 0.3 User Interface - Displays Software Version 405.xx Issue 01/99 0 - 24 0.3.5 "IC Head" Displa y , SIPLA CE 80F 4 /F 5 F…
User Manual Test Program SITEST 0 Introduction to the User Interface of the Test Program
Software Version 405.xx Issue 01/99 0.3 User Interface - Displays
0 - 23
0.3.4 "RV Head" Display
From the "RV head" display, all functions concerning the respective revolver head can be called up.
Fig. 0.3.5 "RV Head" Display (Example "RV head functions")
Legend pertaining to Fig. 0.3.5
➀
Main view
➁ RV head functions
➂ Axis functions
➃ Holding and reject circuit
➄ Placement and pick-up circuit
➅ RV mapping
➆ RV head / camera
➇ Nozzle changer
➀➁➂➃➄
➅
➆ ➇
0 Introduction to the User Interface of the Test Program User Manual Test Program SITEST
0.3 User Interface - Displays Software Version 405.xx Issue 01/99
0 - 24
0.3.5 "IC Head" Display, SIPLACE 80F
4
/F
5
From the "IC head" display, all functions concerning the IC head can be called up.
Fig. 0.3.6 "IC Head" Display (Example "IC head functions")
Legend pertaining to Fig. 0.3.6
➀
Main view
➁ IC head functions
➂ Axis functions
➃ Head board
➄ IC mapping
➅ IC head and IC camera
➆ Flip-chip camera
➇ IC nozzle changer
➈ Coplanarity module
➀➁➂
➃➄➅➆➇ ➈
User Manual Test Program SITEST 0 Introduction to the User Interface of the Test Program
Software Version 405.xx Issue 01/99 0.3 User Interface - Displays
0 - 25
0.3.6 "Flux Dispenser" Display, SIPLACE 80F
4
/F
5
The "Flux dispenser" display contains all buttons required for testing the functions of the flux dispenser.
Fig. 0.3.7 "Flux dispenser" Display (Example "Flux dispenser functions")
Legend pertaining to Fig. 0.3.7
➀
Main view
➁ Flux dispenser functions
➀
➁
