Station Software Version 711.1 (R18-1) / Installation Manual 05/2018 Edition
13
4.1.3 Embedded Software
4.1.3.1 Composition of the File Name
1..6 7 8 9 10 11 12 13 14 15 16 17 18 19
Sub-
system
name
Sepa-
rator
Variant ID Hard-
ware ID
1)
Target
2)
Version Release . File type
Please
refer to
table in
section
4.1.3.2
_ 0 = no
variant
00
0 = BIOS 00
H
00
H
. HEX
_ A =
Variant
(SOKO)
…
… … … . JED
_ ... 99 9 = App 9 FF
H
FF
H
. BHX
Table 4-1: Composition of the file name
1)
Change compared with old file name (from one to 2 digits)
2)
Extended to second CAN
Station Software Version 711.1 (R18-1) / Installation Manual 05/2018 Edition
14
4.1.3.2 Comparison of Old and New Names of the Subsystems
Old subsystem name
(<7xx)
New subsystem name
(7xx)
Name
A AXIALL General axes (including free axis),
excluding DP axes of the C&P20A head
B COMTAB Component table
C VHSAXS Star axis of C&P20A head
E IOMODU CAN I/O module
F (Replaced by AXIALL) Free axis
G TAPCUT Tape cutter
H VHSHED C&P20A head
I TWIHED Twin Head
J VHSAXD DP axis of C&P20A head
L TWIAPR / VHSAPR Pressure regulation valve
(Twin Head / C&P20 head)
M MTCHNG MTC
N ---
O ---
P TWIAXZ Z-axis, Twin Head
Q ---
R TWIAXD DP axis, Twin Head
T CONVEY PCB conveyor
U FEEDER Feeder
V ILLUMI Vision
W VHSAXZ Z-axis, C&P20A head
X GANAXX X-axis
Y GANAXY Y-axis
--- CCPAPR
1)
Pressure regulation valve, CPP head
--- CPPAVA
1)
Valve cluster, CPP head
--- CPPAXD
1)
DP axis, CPP head
--- CPPHED
1)
CPP head
--- CPPSCO
1)
Component sensor
Station Software Version 711.1 (R18-1) / Installation Manual 05/2018 Edition
15
--- CPPSZD
1)
Z-bottom, CPP head
--- WPCAXI
2)
WPC5 feed axis and lift axis
--- WPCHNG
2)
WPC5 / WPC6
--- DLMHED
3)
C&P12 head
--- GATWAY CAN sensor gateway
Table 4-2: Names of the subsystems
1)
as of 702.xx
2)
as of 703.xx
3)
as of 705.03
