HS-60 Service Manual 4 Gantries
03/2003 US Issue 4.5 Special safety instructions when working in the vicinity of powerful magnetic fields
101
WARNING
To avoid damaging the collect&place head, ALWAYS observe the following points when mov-
ing the gantry: 4
– NEVER move the gantry by pushing with your hands against the collect&place head.
– NEVER push the gantry while the Z-axis is lowered.
– Take hold of the cast iron part of the X-axis - ideally near the X-axis toothed belt deflection
pulley - and then move the gantry.
4.5 Special safety instructions when working in the
vicinity of powerful magnetic fields
RISK TO HEART PACE-MAKER WEARERS 4
The permanent magnets of the Y-axis have an extremely powerful magnetic field. Personnel wear-
ing heart pace-makers are NOT permitted to stand in the vicinity of permanent magnets (see
item 1 and 2 in Fig. 4.5 - 1). 4
CAUTION POWERFUL MAGNETIC FIELD 4
Æ Do not wear watches in the vicinity of permanent magnets since they can be damaged.
Æ Do not bring magnetic data media, check or credit cards near permanent magnets - the data
on the data media may be erased by the magnetic field of the permanent magnets.
WARNING RISK OF CRUSHING 4
Do not approach permanent magnets when carrying metal objects made of iron, steel or nickel.
The powerful force of attraction may cause fingers to be crushed. 4
4 Gantries HS-60 Service Manual
4.5 Special safety instructions when working in the vicinity of powerful magnetic fields 03/2003 US Issue
102
4
Fig. 4.5 - 1 Position of the permanent magnets of the Y-axis linear drives
Key
1A, 1B, 1C, 1DPermanent magnets for the Y-axis linear drive for gantries 1 and 4 4
2A, 2B, 2C, 2DPermanent magnets for the Y-axis linear drive for gantries 2 and 3 4
T Transport direction 4
4
T
1D
1C
1A
2C
2B
2A
2D
1B
HS-60 Service Manual 4 Gantries
03/2003 US Issue 4.6 Replacing the elastomeric spring (00301040-01)
103
4.6 Replacing the elastomeric spring (00301040-01)
4.6.1 Tools and equipment
– Set of DIN 911 Allen keys
4.6.2 Parts
25x10.5x50 elastomeric spring, from item number 00301040-01 4
4.6.3 Removing the elastomeric spring
Æ
Switch the placement system off and secure it to prevent switching on again as described in
Section 4.4
, page 100 onward.
DANGER POWERFUL MAGNETIC FIELD 4
Always follow the special safety instructions when working in the vicinity of powerful magnetic
fields (see Section 4.5, page 101 onward). 4
Fig. 4.6 - 1 Replacing the elastomeric spring
Key
1 Elastomeric springs for the X-gantry
2 Gantries 1 and 3: elastomeric spring for the Y-axis
Gantries 2 and 4: reflecting bracket instead of elastomeric spring
3 Gantries 1 and 3: elastomeric spring for the Y-axis
Gantries 2 and 4: item 3 canceled 4
