4 Gantries HS-60 Service Manual
4.7 Replacing the X-axis scale (00329316-01) 03/2003 US Issue
106
Æ Loosen the eleven M2.5 x 5 hexagon socket-head screws (item 3 in Fig. 4.7 - 1) with washers.
Æ Move the head mount (item 6 in Fig. 4.7 - 1) across as far as the elastomeric spring (item 7 in
Fig. 4.7 - 1
) in order to prevent any damage to proximity switches B1 and B2 (item 5 in Fig. 4.7
- 1).
Æ Remove the scale (item 4 in Fig. 4.7 - 1).
4.7.4 Installing the X-axis scale
Æ Carefully insert the scale.
CAUTION 4
Do not touch the incremental tracks with bare fingers. 4
Æ Loosely tighten the eleven M2.5 x 5 hexagon socket-head screws with washer.
Æ Push the scale along the bars as far as the stop (item A in Fig. 4.7 - 1)
Æ Tighten the M2.5 x 5 hexagon socket-head screws.
Æ Use the feeler gauge to set the 0.4 mm gap between the incremental encoder and scale.
Æ Use the two M3x8 hexagon socket-head screws (item 2 in Fig. 4.7 - 1) to fix the incremental
encoder (item 1 in Fig. 4.7 - 1
) to the X-axis.
4.7.5 Settings
Æ Set and calibrate the collect&place head and gantry axes using the SITEST program.
HS-60 Service Manual 4 Gantries
03/2003 US Issue 4.8 Replacing the tensioning keys (00329478-01, 00329485-01)
107
4.8 Replacing the tensioning keys (00329478-01,
00329485-01)
4.8.1 Tools and equipment
– Set of DIN 911 Allen keys
– TSM belt tension measuring device, from item number 00326015-01
– "Measuring belt tensions" operating instructions
4.8.2 Parts
Designation From item number Item in Fig. 4.8 - 1
Tensioning key 00329478-01 (1)
Tensioning key 00329485-01 (2) 4
4.8.3 Removing the tensioning keys
Æ Switch the placement system off and secure it to prevent switching on again as described in
Section 4.4
, page 100 onward.
Æ Push the head mount towards the deflection pulley (item 6 in Fig. 4.8 - 1).
Æ To slacken the toothed belt (item 5 in Fig. 4.8 - 1)
– loosen the locknut (item 11 in Fig. 4.8 - 1
) and
– turn the hexagon socket-head screw counter-clockwise (item 3 in Fig. 4.8 - 1
).
Removing the tensioning key, item 1 (synchronizing disk, short) 4
Æ Loosen the M4 x 5 hexagon socket-head screw (item 8 in Fig. 4.8 - 1).
Æ Lift out the tensioning key.
Removing the tensioning key, item 2 (synchronizing disk, long) 4
Æ Unscrew the hexagon socket-head screw (item 3 in Fig. 4.8 - 1) from the spacer bolt (item 7 in
Fig. 4.8 - 1
).
Æ Lift out the tensioning key.
4 Gantries HS-60 Service Manual
4.8 Replacing the tensioning keys (00329478-01, 00329485-01) 03/2003 US Issue
108
4
Fig. 4.8 - 1 Replacing the tensioning keys
Key
(1) Tensioning key
(2) Tensioning key
(3) M4 x 35 hexagon socket-head screw for tensioning the toothed belt
(4) Head mount
(5) Toothed belt for the X-axis
(6) Deflection pulley
(7) Spacer bolt with Benzing U-clip
(8) M4 x 5 hexagon socket-head screw
(9) Synchronizing disk, short
(10) Synchronizing disk, long
(11) Locknut
