5 Pneumatic Cutter and Empty-Tape Duct Service Manual HS-60
5.4 Overview of Mechanical Layout 03/2003 US Issue
134
Key to Fig. 5.4.2
:
1. Cover plate
2. Cover plate holder, left
3. Cover plate holder, right
4. Screws to fasten the cover plate holder:
2 hexagon socket head screws M4 x 8 DIN 84 or 2 countersunk screws R M4 x 6 DIN 965 each
5. Screws to fasten the cover plate (incl. tape deflector) -> do not loosen!
6. Tape deflector (with moveable blade underneath)
7. Tape deflector holder, left
8. Tape deflector holder, right
9. Screws to fasten the tape deflector holders: 2 socket hex head cap screws M4 x 35 each on
the left and right
10. Screws to fasten the tape deflector: 1 countersunk screw each -> do not loosen!
11. Holddowns (at left and right) with spacers inserted underneath them
12. Deflector plate
13. Screws to fasten the deflector plate: 4 socket hex head cap screws M4 x 8
14. Screws to fasten the cutter on the machine frame
4 socket hex head cap screws M 6 x 25 *)
15. Any disks or plates installed underneath
16. Stationary blade
17. Rubber-metal vibration damper
18. Any disks and spring washers installed underneath
5
*) Loosen these screws only when removing/installing the cutter (see Section 5.6.1
). 5
Service Manual HS-60 5 Pneumatic Cutter and Empty-Tape Duct
03/2003 US Issue 5.5 Diagrams of Pneumatic System and Functional Sequence
135
5.5 Diagrams of Pneumatic System and Functional
Sequence
Fig. 5.5.1 Diagram of Pneumatic System: Cutter per Conveyor Side
