Service Manual HS-60 6 Modular PCB conveyor system
03/2003 US Issue 6.9 Replacing the toothed belt of the relevant PCB conveyor drive (00355553-01)
171
6.9.2 Installation
CAUTION
The new toothed belt must not be stretched or kinked! during the following procedure
Æ Insert the new toothed belt into the motor mount and place the belt around the synchronizing
disk of the geared motor.
Æ Place the toothed belt around the synchronizing disk of the conveyor toothed belt and insert
the synchronizing disk in its mount.
Æ Use a rubber mallet to carefully knock the synchronizing disk into position.
Æ Loosely fasten the DC geared motor with the 4 M3 hexagonal socket-head screws The entire
width of the toothed belt must engage at the top and bottom synchronizing disk.
Æ Install the complete motor unit as described in Section 6.7.3.
Æ Perform the „Final steps including function check“ (see Section 6.18).
NOTE:
After the new drive unit has been installed, you must make certain that the direction of rotation and
the conveyor speed (motor voltage) are correct.
After reconnecting the geared motor, you will only need to check the direction of rotation.
6 Modular PCB conveyor system Service Manual HS-60
6.10 Replacing the conveyor toothed belt (00364847-01) 03/2003 US Issue
172
6.10 Replacing the conveyor toothed belt (00364847-01)
DANGER
Please observe the safety instructions in Chapter 2.
NOTE
The following diagrams apply for the standard conveyor system (fixed side - right). The mount is
installed on one side of the conveyor, while the DC geared motor is mounted on the other side.
6.10.1 Parts
– 00356851-01 Synchroflex toothed belt for input-, output- or intermediate conveyor
– 00356850-01 Synchroflex toothed belt for placement area 1 + 2
Service Manual HS-60 6 Modular PCB conveyor system
03/2003 US Issue 6.10 Replacing the conveyor toothed belt (00364847-01)
173
Fig. 6.10.6 Overview of conveyor toothed belt (example with mounting))
Key
(1) Input conveyor (4) Placement area 2 (HS-60 only)
(2) Placement area 1 (5) Output conveyor
(3) Intermediate conveyor (HS-60 only)
