Service Manual HS-60 2 Operational safety

03/2003 US Issue 2.1 Safety instructions

2 Operational safety

2.1 Safety instructions

2.1.1 Conventions for the use of hazard symbols

This Service Manual contains notes that must be observed to guarantee your personal safety and

to avoid damage to equipment. These notes are highlighted by warning triangles and are indicated

as follows according to the level of risk:

DANGER or DANGER

as used in this Service Manual means that death, severe injury or considerable damage to equip-

ment will occur if the danger instructions are not followed.

WARNING or

as used in this Service Manual means that death, severe injury or considerable damage to equip-

ment may occur if the warning instructions are not followed.

CAUTION or

as used in this Service Manual means that slight injury or damage to equipment may occur if the

caution instructions are not followed.

NOTE

as used in this Service Manual provides information on the product or indicates a part of the Ser-

vice Manual that requires particular attention.

2.1.2 Qualified personnel

Qualified or adequately trained personnel means that these people are familiar with the setting up,

operation and maintenance of automatic placement systems and add-on devices and are suitably

qualified, e.g.

– have been trained, instructed or authorized to switch on and off, isolate, earth and identify elec-

trical circuits and system components in accordance with normal safety standards.

– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-

cordance with normal safety standards.

– have received first aid training.

2 Operational safety Service Manual HS-60

2.1 Safety instructions 03/2003 US Issue

2.1.3 Use as prescribed

The product must only be used for its intended purposes as described in the catalogues and tech-

nical descriptions, namely the placement of SMD components, and only with the third-party equip-

ment and components recommended or permitted by SiemensDematic Use for a different or

extended purpose is not prescribed.

If the product is not used as prescribed, SIEMENSDEMATIC AG accepts no liability for any dam-

age that may occur and does not guarantee that the components will work properly and without

problems.

Use as prescribed also includes compliance with all the instructions in the user manual.

For the product to operate correctly and reliably, it must have been transported, stored, erected

and assembled correctly and must be operated and maintained with care.

2.1.4 Failure to use as prescribed

Failure to use the product as prescribed can result in both danger to life and limb and material

damage. For this reason any use that is not prescribed is not allowed. If the product is not used

as prescribed, SIEMENSDEMATIC AG accepts no liability for any damage that may occur and

does not guarantee that the components will work properly and without problems.

Examples of failure to use the product as prescribed:

– Placement of components that do not meet the permitted specification

– The use of component feeders that have not been approved

– The use of unauthorized accessories and additional modules

2.1.5 Important notes on operational safety

The following points MUST be observed in order to maintain operational safety:

2.1.5.1 General

Æ The operational safety of SMD automatic placement systems can be guaranteed only if the

system is used as prescribed and in accordance with the instructions in the User/Service Man-

uals.

Æ Always follow any safety regulations specific to your country.

Æ Make sure that the warning labels are always clearly identifiable and always easily readable.

Æ Replace any damaged warning or notice labels. Replace any labels that are missing.

Æ The machine key for releasing the covers on the machine must be kept in a safe place where

it is only accessible to qualified personnel.

Service Manual HS-60 2 Operational safety

03/2003 US Issue 2.1 Safety instructions

NOTE

The machine owner, and only the machine owner, is responsible for the safekeeping of the

machine key and for ensuring that it is handed over to authorized persons. 2

Æ If it is necessary to work on the machine and you do not have adequately trained personnel

within your operation, always call in a SIEMENSDEMATIC service technician. SIEMENSDE-

MATIC AG will not accept liability for any damage or consequential damage that is the result

of incorrect work.

Æ If particularly hazardous situations are identified while the machine is in use, the machine

owner must immediately notify the manufacturer in writing so that appropriate action can be

taken to reduce the potential danger.

WARNING

In spite of all the safety precautions taken by the manufacturer, failure to use the system as pre-

scribed can result in severe physical injury (e.g. from the moving gantry or lifting table) and/or con-

siderable damage to equipment. For the machine to be safe, it must be used correctly by qualified

personnel and all warnings must be observed. Some work on the machine (e.g. setting up) re-

quires training that goes beyond the scope of this Manual. 2

2.1.5.2 Safety of operators and other persons

Æ Machine operators must only carry out work for which they have been adequately trained and

with which they are totally familiar.

Æ NEVER open one of the protective covers if you are not totally familiar with the use and func-

tioning of the machine! Do not open the protective covers during operation unless you are told

to do so in this Manual or in the station software dialog.

Æ Only trained and qualified personnel may set the key switch to setup mode ("I").

During operation, do not set the key switch to the "I" position (setup mode) unless prompted to

do so in this manual or by the station software. 2

Æ NEVER place your head or arms in the gantry and lifting table traveling range while the station

is switched on!

Æ For your own safety, wear work clothes that conform to the guidelines of the professional as-

sociation, i.e. no wide sleeves etc.

Æ Reduce the risks by not wearing scarves, chains or ties at your work post.

Æ People with long hair must wear a protective head covering.
