2 Operational safety Service Manual HS-60
2.2 Warning labels 03/2003 US Issue
30
2.2.7 Warning label "laser class 2" on the PCB conveyor
2
Warning label "Laser class 2" on the PCB conveyor, item no. 03009347-01
2
Fig. 2.2 - 8 Warning label "Laser class 2" on the PCB conveyor
2
2
LASER RADIATION!
Do not look into beam
Laser class 2
Service Manual HS-60 2 Operational safety
03/2003 US Issue 2.3 Laser classification
31
2.3 Laser classification
2.3.1 Laser class 1
2.3.1.1 Classification of the whole machine
2
PLEASE NOTE: 2
Modules in laser classes 1 and 1M are not identified.
2.3.1.2 Classification of the camera systems
2
2.3.2 Laser class 1M
Do not look directly at this with optical instruments!
2
2
All installed camera systems and the whole machine when ready
for operation are assigned to laser class 1.
The laser classes are determined according to DIN EN 60825-1.
2
The following camera systems are assigned to laser class 1:
– PCB multicolor camera
2
The following camera systems are assigned to laser class 1M:
– 24 x 24 component camera on the 12-segment Collect&Place head
– 16 x 16 DCA camera on the 12-segment Collect&Place head
2 Operational safety Service Manual HS-60
2.3 Laser classification 03/2003 US Issue
32
2.3.3 Laser class 2
The following modules are assigned to laser class 2:
– Laser light barrier, placement area 1 in the PCB conveyor
– Laser light barrier, placement area 2 in the PCB conveyor
– PCB barcode scanner
2
2
Laser radiation
Do not look into beam!
