Service Manual HS-60 8 Movable Component Changeover Table
03/2003 US Issue 8.4 Overview of mechanical construction
329
Key for Fig. 8.4.1
:
1. Component changeover table HS-50/60 (without feeders)
2. Feeder modules or dummy modules **)
3. Component table plate
4. 1 Bellows cylinder for height adjustment *)
5. Communication unit
6. 2 Fixed castors *)
7. 2 Guide castors *)
8. Tape container
9. Bowden cable *)
10.Component table in "top" position" (= position to connect / disconnect)
11. Handle, can be bent after the activator tube has been pushed up.
12. Component table in "bottom" position (= position when connected)
13. Insertable tape reels: 7", 10", 15 ", 17", 19"
14. Knockout spindle for tape reels (if needed) *)
15.Cable for component table
*) Item No. -> see Section 8.2
**) Option, Item No.:
for feeder modules -> see SIPLACE service manual, chapter "Feeder modules".
for dummy modules ->Item No. 00345462-01
8 Movable Component Changeover Table Service Manual HS-60
8.5 Resolving problems 03/2003 US Issue
330
8.5 Resolving problems
DANGER
Parts of your body may be pinched, crushed or severed by the component changeover table
(see Section 8.1
).
No substantial lateral force is to be exerted on the component changeover table after it has been
disassembled (danger that it might tip over), therefore:
- Do not lean against it and do not brace any items against it.
- Place the component changeover table on a horizontal surface and secure it to prevent it from
rolling away by itself.
Once the component changeover table has been moved out of the machine, NEVER connect the
plugs to the machine frame (= improper use = DANGER!)
Moving the component changeover table out of the machine leaves the cutter (etc.) accessible:
This increases the risk of injury on the cutter’s movable or stationary blades even while the ma-
chine is switched off.
NEVER reach into the cutter from below or into the empty-tape duct from above, not even to re-
solve a problem (e.g., jammed tape) involving the disassembly of the component changeover ta-
ble. 8
Service Manual HS-60 8 Movable Component Changeover Table
03/2003 US Issue 8.5 Resolving problems
331
8.5.1 Preparatory steps
Æ Move the component changeover table out of the machine, as described in the SIPLACE
HS-60 User Manual (hold the handle with both hands!)
If an empty, movable component changeover table is available, first proceed as follow
Æ Pull out the plug-and-socket connections of all of the feeder modules on the faulty compo-
nent changeover table.
Æ Place the feeder modules incl. the tape reel and knockout spindles (see Fig. 8.4.1 -> 2, 13,
14) in correct order on the new component table (in accordance with the specifications for
set-up optimization), insert the tapes and check the allocation of component / track (com-
ponent bar code scanner).
If there is an external set-up location available, carry out the setting up and inspection there
(see also Section 8.5.7
"Final Steps").
Æ Connect the new component changeover table to the machine, as described in the User
Manual.
Æ Resolve the problems with the dismantled component changeover table as indicated in the
relevant section below.
Æ If no other component changeover table is available,
continue as follows after resolving the problems as required:
– When exchanging the bellows cylinder:
Take the feeder modules from the changeover table and place them on a clean surface. In
this case, the tape reels can remain in the container.
Æ When exchanging the guide castors and fixed castors:
Same steps as above for exchanging the bellows cylinder.
In addition, remove all of the tape reels from the container and put them down in order.
– When exchanging the component table cable, the communications unit or the bowden ca-
ble: The feeder modules do not have to be dismantled.
