.ini files
A - 6 Vision 2007 4.10 User Manual Rev 01
A.3.3 Production tab
INI section: [System]
A Default bar code coding type.
C Defines the socket port used in the network communication between the AOI system and
the supervisor.
H Maximum number of errors to output when printer is active.
K Defines the Production Program Directory.
Mark Key name Initial value Min value Max value
A Barcod coding type CODE 128
B Server name SERVER
C Socket Port(0,1) 0 0 255
D PrinterActive(0,1) 0 0 1
E Print one page by board(0,1) 0 0 1
F Writing in database(0,1) 0 0 1
G Orientation if opposite face contains default(0,1) 0 0 1
H Max error to print 50 1 500
I Line space distance 100 10 1000
J Number of line per page 60 1 1000
G
F
D
E
I
J
B
K
Maintenance default values
.ini files
Vision 2007 4.10 User Manual Rev 01 A - 7
A.3.4 Tools tab
INI section: [Tools]
Mark Key name Initial value Min value Max value
A Direct amber(1,255) 1 1 255
B Direct green(1,255) 1 1 255
C Horizontal amber(1,255) 1 1 255
D Horizontal green(1,255) 150 1 255
E Repetability cycle number 10 2 100
F Version Number 1 0 1000
A
B
C
F
E
D
Maintenance default values
.ini files
A - 8 Vision 2007 4.10 User Manual Rev 01
A.3.5 Data export tab
INI section: [Statistics]
Mark Key name Initial value Min value Max value
A Sample size 30 1 250
B Active statistic transfert(0,1) 0 0 1
A
B
Maintenance default values
