22
SM411F
Conveyor Ass’y (2/5)
18
23
24
12
21
4
5
13
17
9
3
7
2
16
3
15
8
6
11
10
19
1
22
14
20
23
SM411F
Conveyor Ass’y (2/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 EP08-900160 SERVO_MOTOR_A5 MSMD012G1A 1 EP08-900121
2 J70531109A MANUAL_HANDLE J70531109A 1
3 MC03-900008 BALL BEARING [6000ZZ] 4 MC03-900023
4 MC03-900080 BALL BEARING[608ZZ] 2
5 MC03-900121 BALL BEARING[F608ZZ] 2
6 MC05-900026 TIMING BELT [258-3M-9] 1
7 MC19-900014 PULLEY-WIDTH [20-XL-025] 2
8 MC19-900015 PULLEY-MOTOR [P32-3M-9] 1 J6609015A
9 J7053194A BEARING NUT [J7053194A] 2
10 J7053725A SUPPORT-WIDE ADJUST[J7053725A] 2
11 J7053726A SCREW STAND[J7053726A] 2
12 J7053661B WIDTH TENSION SPACER[J7053661B] 2 J7053661A
13 J7053662A TENSION BEARING PIN[J7053662A] 2
14 J70531206A FIX_STAND J70531206A 2
15 J7053780A BRACKET-SERVO MOTOR[J7053780A] 1
16 J7153326A WIDTH PULLEY COLLAR[J7153326A] 2
17 J7153330A PULLEY SHAFT[J7153330A] 1
18 J7053660A TENSION BKT[J7053660A] 2
19 MC13-900229 LEAD_SCREW_350 MC13-900229 2
20 MC13-900230 LEAD_SCREW_250 MC13-900230 2
21
22
23
24 J7053677A MOVE STAND[J7053677A] 2
24
SM411F
Conveyor Ass’y (3/5)
28
38
24
34
24
11
35
33
21
17
8
15
17
8
15
14
14
40
41
40
20
26
39
28
26
39
28
25
25
29
26
26
39
28
27
39
32
28
22
26
29
31
6
29
18
16
29
13
12
8
9
27
26
29
38
28
37
32
A
29
17
10
9
36
23
6
19
23
6
29
6
1
6
5
30
2
4
3
A
7
29
26
29
29
