Page HANWHA TECHWIN 62 SM411F Air Ass’y (4/5) BUT Cylinder (Push-Operated) BUT Cylinder (Pull-Ready) ANC Shutter Cylinder-Rear (Push-Open) Conveyor PCB Stopper Cylinder (Push-Operated) ANC Shutter Cylinder-Front (Push-Cl…
Page
HANWHA TECHWIN
61
SM411F
Air Ass’y (3/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 HP11-900094 VACUUM_GENERATOR VKMH07A-S448S2-B06 2
2 HP06-900251 STRAIGHT FITTING [SS8-1/8] 2
3 HP06-900051 ELBOW FITTING 2 HP06-900264
4 HP06-900050 UNION Y FITTING 2 HP06-900199
5 FC14-900724 PLUG [PT 1/8] 6
6 HP13-900089 MULTI TUBE[UML-408 (BL-BK6-BL)] 7
7 HP09-900118 REGULATOR HP09-900118 2 HP09-900110
8 J90581001A SM330_MANIFOLD_ASSY J90581001A 1
9 HP06-900081 DOUBLE_UNIVERSAL_ELBOW_06 KQ2VD06-02S 1
10 HP06-900082 DOUBLE_UNIVERSAL_ELBOW_08 KQ2VD08-02S 2
11 HP06-900028 ELBOW FITTING [KQ2L06-02/PL6-02] 2
12 FC14-900722 PLUG [PT 3/8] 1
13 HP06-900290 MALE ELBOW[KQ2L12-03] 1
14 J2100009 MANIFOLD [0131-611008] 1
15 FC14-900637 PLUG[PT 1/4 (SUS)](bio) 1
16 HP06-900255 STRAIGHT FITTING KQ2H04-M5 1
17 HP09-900108 REGULATOR 1 HP09-900112 /HP09-900108
18 J90831313C AIR_INDICATOR_CABLE_ASSY 1 J90831313C /TE07-900099 /TE07-900092
19 HP06-900026 ELBOW FITTING [KQ2L12/PL12-04] 2 HP06-900273
20 HP06-900056 ELBOW FITTING [KQ2L04-01] 1
21 HP04-900029 MIST_SEPARATOR_ASSY 1
Page
HANWHA TECHWIN
62
SM411F
Air Ass’y (4/5)
BUT Cylinder (Push-Operated)
BUT Cylinder (Pull-Ready)
ANC Shutter Cylinder-Rear (Push-Open)
Conveyor PCB Stopper Cylinder (Push-Operated)
ANC Shutter Cylinder-Front (Push-Closed)
Conveyor PCB Stopper Cylinder (Pull-Ready)
Conveyor Edge Fixer Regulator
SM411F_MANIFOLD
ANC Shutter Cylinder-Front (Push-Open)
ANC Shutter Cylinder-Rear (Push-Closed)
ڰڍڈڏڈړڅڐ
ڰڍڈڏڈړڅڐ
C
C
ڠڟڢڠٻڡڤڳڠڭٻڜڮڮڴ
ڠڟڢڠٻڡڤڳڠڭٻڜڮڮڴ
ڮگڪګګڠڭٻڜڮڮڴڃڲڪڭڦڄ
ڮگڪګګڠڭٻڜڮڮڴڃڲڪڭڦڄ
ڝڰگٻڜڮڮڴ
ڝڰگٻڜڮڮڴ
ڞڪکڱڠڴڪڭٻڜڮڮڴ
ڞڪکڱڠڴڪڭٻڜڮڮڴ
ڮڴڎڌڍڋڈڍڋڈڦڭڲڋڋڔړ
ڮڴڎڌڍڋڈڍڋڈڦڭڲڋڋڔړ
ڰڍڈڏڈڏڅڍډڐڃڝڧڰڠڄ
ڰڍڈڏڈڏڅڍډڐڃڝڧڰڠڄ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڑڅڏڃڴڠڧڧڪڲڄ
ڰڍڈڏڈڑڅڏڃڴڠڧڧڪڲڄ
ڰڍڈڏڈڑڅڏ
ڰڍڈڏڈڑڅڏ
ڜکڞٻڜڮڮڴڃڡڭڪکگڄ
ڜکڞٻڜڮڮڴڃڡڭڪکگڄ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
ڃڝڧڰڠڄ
ڃڝڧڰڠڄ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
ڜکڞٻڜڮڮڴڃڭڠڜڭڄ
ڜکڞٻڜڮڮڴڃڭڠڜڭڄ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
ڃڝڧڰڠڄ
ڃڝڧڰڠڄ
ڰڍڈڏڈڏڅڍډڐ
ڰڍڈڏڈڏڅڍډڐ
3
1
2
5
8
9
12
11
10
10
2
11
10
6
7
13
14
4
12
Page
HANWHA TECHWIN
63
SM411F
Air Ass’y (4/5)
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 HP03-900039 EDGE CYLINDER 1
2 HP06-900027 FITTING [KQ2L04-M5/PL4-M5M/SQL04-M5] 2
3 HP09-900109 REGULATOR 1
4 HP14-900040 SOLENOID VALVE
5 J67061080A AIR CYLINDER[MHY2-01-IU2054-D-M9N(3m)] 1
6 HP03-900013 CYLINDER CM2C32-50-XC3BB HP03-900040 1
7 HP06-900056 ELBOW FITTING KQ2L04-01/SQL04-01S-W 2
8 HP06-900263 HOSE NIPPLE 1
9 HP03-900032 AIR CYLINDER BDAS 10X5-1A-ZC153A2 1
10 HP03-900032 AIR_CYLINDER 1
11 HP14-900085 SPEED CONTROLLER [SS4-M5MA] 2
12 HP06-900264 ELBOW FITTING [KQ2L08-01S]
13 FC14-900640 PLUG FITTING KPT18
14 HP06-900016 FITTING [KQ2S04-M5/POC4-M5M]
