T ranslation of the original ENGLISH 4. TRANSPORT AND ST ORAGE 451820.66.03_EN 2020-05-05 27 4.5 Storing the cooling unit The cooling unit must be stored in a dry frost-free room on a flat surface or using additional bea…
4. TRANSPORT AND STORAGE ENGLISH Translation of the original
26
451820.66.03_EN
2020-05-05
4.4 Transport – crane
The upper frame contains sling lugs for transporting cooling units with a four-point attachment.
(See figure 1)
In the case of cooling units without sling lugs, crane transport claws are attached to the lower frame.
(See figure 2)
Load suspension devices
The load suspension devices fulfil the necessary requirements for attachment with equal rope or
chain lengths.
• Slinging ropes (rope suspension) according to DIN 3088
• Slinging chains (chain suspension) according to DIN 5687/5688
Rope inclination angle
The rope inclination angle as shown in the figure must be complied with.
Lifting speed
The unit must be lifted slowly.
(V
lift
<10 m/min – creep lifting, smooth lifting)
Setting down the cooling unit
To avoid deformations on the lower frame, the cooling unit must be set down on an even surface.
T ransport with crane - figure 1 T ransport with crane - figure 2
Example figure
Translation of the original ENGLISH 4. TRANSPORT AND ST ORAGE
451820.66.03_EN
2020-05-05
27
4.5 Storing the cooling unit
The cooling unit must be stored in a dry frost-free room on a flat surface or using additional beams.
Permissible storage temperatures: -20°C to +60°C.
The decommissioning steps must always be carried out if the unit is to be stored at ambient
temperatures below 0°C.
(See chapter 8 "Decommissioning/shutdown")
4. TRANSPORT AND STORAGE ENGLISH Translation of the original
28
451820.66.03_EN
2020-05-05
