Maintenance ■ Programmers
- 120 - Data I/O ■ 096-0465-001C
The wrist strap Data I/O
PN is 440-0021-001.
RUNNING THE PROGRAMMER DIAGNOSTIC TEST
To run diagnostic tests on FlashCORE programmer(s):
1. Finish a job if one is running; wait for the PNP head to park.
2. Turn OFF the programmer circuit breaker at the Power Panel (down
position).
3. Exit CH700 to return to TaskLink.
WARNING: ESD hazard! To prevent ESD shock, before you
touch the Socket Adapter, discharge static electricity from
yourself by touching a common ground or an unpainted metal
surface.
When at the PSV5000 Machine, always wear a wrist strap containing a 1
M-ohm min. to 10 M-ohm max. current limiting resistor. Connect the
antistatic wrist strap to the grounding socket on the front or back of the
PSV5000 Machine.
WARNING: Possible collision hazard! The high speed and force of the gantry
can seriously harm anyone working inside the workspace.
When working within the machine workspace, moving the PNP head must
be the responsibility of only one qualified individual. All others must stay
clear of the machine controls to prevent injury to that person.
Ensure that a job is Paused or Finished, or the system power is OFF prior to
opening any safety doors.
4. Remove the Socket Adapter from the target programmer and insert the
Diagnostic Adapter Board, ensuring that it aligns correctly on the adapter
pins. Screw down the two bracket screws (4 mm hex key).
5. Turn the programmer circuit breaker at the Power Panel ON (up
position).
6. Start TaskLink and click Tools > Run Programmer Diagnostics.
Programmers Replacing a Programmer
PSV5000 Owner’s Manual - 121 -
7. On the Diagnostics window, select the programmer with the DAB
installed.
8. Click Test All.
The pass/fail test results are displayed in TaskLink and are also written
to /fdrroot/system/diaglog.txt (and to the CF-card of the target
FlashCORE programmer). These files can be viewed in TaskLink and
saved (on the Handler Computer).
If any of the tests show Fail in the TaskLink display, contact your nearest
Data I/O Service Center for repair options. To help our service personnel
diagnose the problem, please e-mail both the
eventlog.txt and diaglog.txt files.
Sample dialog.txt file:
Diagnostic Pass #1
Run Vpp Overcurrent test.
DUT 1 G1 Vpp overcurrent is sensed at 57 mA.
DUT 1 G2 Vpp overcurrent is sensed at 57 mA.
DUT 1 G3 Vpp overcurrent is sensed at 57 mA.
DUT 1 G4 Vpp overcurrent is sensed at 57 mA.
DUT 2 G1 Vpp overcurrent is sensed at 57 mA.
DUT 2 G2 Vpp overcurrent is sensed at 57 mA.
DUT 2 G3 Vpp overcurrent is sensed at 57 mA.
DUT 2 G4 Vpp overcurrent is sensed at 57 mA.
Error: DUT 3 G1 Vpp overcurrent is not sensed from 50 mA to 70
mA.
Error: DUT 3 G2 Vpp overcurrent is not sensed from 50 mA to 70
mA.
Error: DUT 3 G3 Vpp overcurrent is not sensed from 50 mA to 70
mA.
Error: DUT 3 G4 Vpp overcurrent is not sensed from 50 mA to 70
mA.
DUT 4 G1 Vpp overcurrent is sensed at 57 mA.
DUT 4 G2 Vpp overcurrent is sensed at 57 mA.
DUT 4 G3 Vpp overcurrent is sensed at 57 mA.
DUT 4 G4 Vpp overcurrent is sensed at 57 mA.
Diagnostics failed.
Maintenance ■ Programmers
- 122 - Data I/O ■ 096-0465-001C
Replacing a Programmer
If a programmer is not working properly, it can be removed and replaced
with another one. Within these instructions are notices where steps differ
for LumenX programmers—denoted by the logo.
TOOLS REQUIRED
• Cable Tie tool
• Clippers to cut cable tie
• 3 mm hex key (Allen wrench)
• Access door key that came with your PSV5000
WARNING: Electric shock hazard! Injury or death may result
from contact to parts inside the machine. Shut off the PSV5000
System by turning OFF the main power switch before working
on or near the gantry, before opening any access doors or removing any
cabinet panels.
To remove a FlashCORE programmer:
1. Properly turn OFF the PSV5000 sub-systems and machine power.
See Shutting Down the PSV5000 System on page 38.
2. With the supplied door key, open the lower, right front access door.
3. Locate the target programmer and follow the heavy gray power cable
to the connection panel on the right side of the machine. Refer to the
figures below.
4. Mark the cable (to re-install in the same place) and pull the
connector straight out from the PCB. LumenX programmers
have two connectors per programmer—mark and disconnect both.
