Maintenance ■ Handler Computer
- 130 - Data I/O ■ 096-0465-001C
Installing CH700 Software Updates
CH700 Software updates are periodically published with improvements.
Delivery depends on contract options.
To install new CH700 Updates on the Handler Computer, insert the
CH700 CD and follow instructions in the Instructions.rtf
file.
NOTE: Your existing
winAH400.ini
will not be replaced so all your settings
will remain the same.
NOTE: Updating TaskLink (FC) and Job Runner or Job Creator (LX) require
different CDs than the CH700 updates. For more information, see the
online Help for TaskLink or Job Runner or Job Creator.
NOTE: PSV5000 System algorithms are updated periodically and are
available depending on your maintenance plan. For more information
about update kits or the support agreement plan go to
http://www.dataio.com/Support/Software-Firmware
Algorithms are updated via TaskLink (FC) and Job Creator (LX). For more
information see TaskLink Help or Job Creator Help. To search for specific
device support visit our Device Search web page:
www.dataio.com/Support/Device-Support/Device-Search
An
APS
is our
Annual
Programmer
Support
Agreement.
Troubleshooting Common Error Messages
PSV5000 Owner’s Manual - 131 -
Troubleshooting
This section contains solutions to problems that may arise during
operation of the PSV5000.
Troubleshooting for the Tape Output System is covered in a separate
heading; see Tape Output System Maintenance on page 140.
Also, see PSV5000 on-screen Help for a more detailed Troubleshooting
chart.
HEADINGS BELOW COVER THESE TOPICS:
Common Error Messages
Collect all PSV5000 System Logs on page 133
Programming Problems on page 133
Pick and Place Problems on page 137
Air Pressure Problems on page 138
Tray Feeder Problems on page 139
Handler Computer Failure on page 139
Common Error Messages
Lamp Color Error Messages Possible Resolution
Red
• Cannot connect to the
motion controller.
• Check that both Emergency Stop buttons are
OFF.
• Check that all safety doors are closed.
• Properly shut down the PSV5000 Machine if
possible, and restart the system.
Red
• E-STOP
ACTIVATED but the
OK button is grayed
out (unavailable)
•
heck that both E-Stop buttons are
released.
• Check that all safety doors are closed.
• If a restart is necessary, press Ctrl + Alt + Del
on the keyboard
Maintenance ■ Troubleshooting
- 132 - Data I/O ■ 096-0465-001C
Yellow
• Tray not present
PSV5000 does not detect the tray and when
you click Run, you get error message Tray Not
Present; or the Run window shows a tray
where there is none.
• Re-install the tray.
• At the Run window, the Tray Present Sensor
should be ON.
• If the tray is still not detected, remove the
tray and place a finger over tray present
sensor.
–If sensor is working, tray outline appears.
Re-install tray.
–If sensor is not working, the tray outline
does not appear—contact Data I/O
Customer Support or a local Data I/O
approved service representative
Red
• Z MOTION ERROR
800: LIMIT
EXCEEDED ON AXIS 2
Conditions: A Red ERROR box appears in
bottom right corner of the Monitor.
Contact Data I/O Customer Support or a local
Data I/O approved service representative.
Red/Yellow
• Error Tape Out • If a device is jammed in the Tape Output
System, clear it. Acknowledge the error
message by pressing the ESC key. Then click
OK on the PSV5000 Monitor.
• If above doesn't work, call the Service
Technician.
Red
• Main Air OFF • Check that the main input air valve is in the
ON position.
• Check that the main air hose is connected.
• Check that the air pressure is within the
required range (green LED readout instead of
red.)
• Contact Data I/O Customer Support or a
local Data I/O approved service
representative.
Red
• Vacuum error • See Adjusting the Vacuum Generator Sensor
on page 105.
• Contact Data I/O Customer Support or a
local Data I/O approved service
representative.
