Administrative Functions ■ Safety Message and Precautions
- 62 - Data I/O ■ 096-0465-001C
Safety Message and Precautions
For your safety and preventing loss of time and damage to equipment,
this manual uses special symbols, paragraphs, and color to call your
attention to hazardous situations and recommend safe practices to help
avoid them.
Refer to Using This Manual on page - 1 - (in the Preface) for symbols and
fonts used for safety messages.
Refer to Safety Systems on page 12 for safety regarding Emergency Stops,
the safety doors, and ESD.
Administrator Functions ≡ Reference List of Operator Functions
PSV5000 Owner’s Manual - 63 -
Administrator Functions
Administrators are responsible for creating Tasks in TaskLink™ and Job
Creator, and for other functions not generally performed by operators.
Administrators would likely perform these functions:
• Editing the winAH400.ini File on page 64
• Creating a Task in TaskLink on page 64
• Creating Security Profiles on page 65
• (Optional) Do a First Article Test on page 66
• (Optional) Setting TaskLink to Operator Mode on page 68
• Enhanced Yield Programming on page 68
• Teaching the Workspace Locations on page 69
• Optimize Movetimes on page 70
• Monitoring Statistics on page 71
• Maximizing Programming Yields on page 77
• (Optional) Creating a Data File from a Master Device on page 80
• Creating a Laser Marking File (if marking) on page 81
• Automotive Performance Pak on page 89
These functions are discussed in this section.
Reference List of Operator Functions
These functions for operators are discussed in the separate Operators
Manual.
NOTE: All users, administrators, and operators should know these
procedures.
Checking the System
Installing Input/Output Media
Installing Socket Adapters and Actuator Plates
Installing the Correct Probe
(Optional) Installing the Correct Shuttle Cups
Turning PSV5000 System Power ON
Selecting a Job (Starting CH700 via TaskLink or Job Runner)
(Optional) Preselecting Programmers
Setting Media and Options—the Setup window
Starting Programming
Administrative Functions ■ Administrator Functions
- 64 - Data I/O ■ 096-0465-001C
—After Starting a Job...
Stopping the System
Light Tower Interpretation
(Optional) Changing Programmer Status
Turning PSV5000 System Power OFF
(Optional) Operating the Tray Feeder
Editing the winAH400.ini File
The winAH400.ini file can be edited to add or remove options which
determine their availability in the CH700 Setup window. It also sets
non-programming features such as language and which events cause
warnings to display. This is a text file that can be edited in text editors
such as Notepad or UltraEdit. Do not use Microsoft Word or other word
processors since they may add hidden special characters such as
end-of-page characters.
CAUTION: File corruption hazard! Before making any changes to your
winAH400.ini file, save a backup copy.
The winAH400.ini is on the Handler computer in the C:\CH700\ folder.
Creating a Task in TaskLink or Job Creator
TaskLink stores Tasks (settings for programming job) for FlashCORE
programmers in a Task database file (*.TSK). A Task contains all the
information necessary for programming and testing specific devices with
a specific algorithm.
Job Creator stores Jobs for LumenX programmers in directory
C:\LumenX\Jobs. A Task contains all the information necessary for
programming and testing specific devices with a specific algorithm.
SETTINGS AND FILES SELECTED FOR TASK/JOBS
Tasks and Jobs include:
• Device settings - identifies a specific device (or family of devices to
select from)
• Data file name and apropos settings
• System settings - Package file name
More information
about the
winAH400.ini file is in
the CH700 on-screen
Help.
Once a Task is
selected and a Pass
Limit is set, the Task
is referred to as a job
to run on the
PSV5000 System. The
same Task can be
used for many
FlashCORE jobs.
Note that operators
can change the Pass
Limit in the CH700
Setup > Job Info
tab.
