Administrator Functions ≡ Creating Security Profiles
PSV5000 Owner’s Manual - 65 -
• Process settings - Continuity check, electronic ID check, blank
check, erase, verify, program, and device marking/labelling
information.
• (Optional) Setting the Pass Limit (the quantity of devices to
program for this job) after clicking Run.
In addition to containing all device-specific settings, a Task/Job
references these files:
File Information
Package File
(*.txt)
For instructions on creating a Package File,
see Teaching the Workspace Locations on page
69.
Data File (*.hex
or *.bin, for
example)
The data file contains your data to be
programmed into the devices.
Laser Marking
File
See (Optional) Creating a Laser Marking File on
page 81.
TASK/JOB CREATION IS DETAILED IN THE SOFTWARE ONLINE HELP
For complete instructions on how to create a Task/Job:
• in TaskLink see TaskLink’s online Help Topics.
• In Job Creator see Job Creator’s online Help Topics.
Both applications will automatically start the CH700 Application
Software when Run is clicked.
(OPTIONAL) PRESELECTING PROGRAMMERS
When CH700 starts, programmers that are not used for a particular job
can be turned off to improve efficiency; see the PSV5000 Operators
Manual for more. Note that operators also have access to this feature.
It is NOT necessary to restart programmers between jobs.
Creating Security Profiles
With the Security Dialog in CH700, administrators can create and
manage user profiles to control security by allowing different rights to
different profiles.
To create a new profile:
Definition: A Task
becomes a ‘Job’ once
a Task is set to Run
and a Pass Limit is
requested and set. A
Task can be used for
many FlashCORE
Jobs.
Job Creator for
LumenX
programmers uses
only the term Jobs
(does not refer to
Tasks).
Administrative Functions ■ Administrator Functions
- 66 - Data I/O ■ 096-0465-001C
Use the physical
keyboard instead of
the on-screen
keyboard when
entering passwords.
1. At the Main CH700 (start) window, clicking Start will open the
Security Dialog in the background. It may be obscured by other
dialogs.
2. In the Security Dialog, use the drop-down arrow to select Supervisor.
3. Enter the password.
4. Click Edit Users.
5. Type a name into the Name field.
6. Type a password into the Password field.
7. Check the box next to each stated right (privilege) for the new user.
For example: if the new user is to create or edit Package Files for
jobs, check Teach Package.
8. Click Save (the diskette image).
(Optional) Do a First Article Test
Prior to programming hundreds of devices, a newly created TaskLink
Task is tested. Follow your company’s First Article Test Plan. The two
methods discussed below are 1) Prior to creating a Package file, and 2)
after creating it.
TEST PRIOR TO CREATING A PACKAGE FILE
Outlined below is a suggested test process using Data I/O’s desktop
programmer called FlashPAK III. This method allows testing without first
having to create the Package File required for PSV5000.
1. Create a new Job for FlashPAK—
1a. In TaskLink, set the Programming System to FlashPAK
(System > Select Programming System > FlashPAK).
1b. Open Task Manager and create a new Task with the Add
button.
1c. Create the Task as usual in the Edit dialog.
2. Test the new Job on FlashPAK—
2a. Using the Load button, send your new Task to a PC Card,
or, if the FlashPAK is on a network, select it.
2b. Test the Task on the FlashPAK by programming a device
and verifying the results.
3. Duplicate the Job for your PSV5000 System—
For help with FlashPAK
see its Operator’s Guide.
Administrator Functions ≡ (Optional) Do a First Article Test
PSV5000 Owner’s Manual - 67 -
3a. If the job passed the tests, in TaskLink Task Manager,
select the Task and click Duplicate. Enter a name and click
OK.
3b. Edit the Task so that it can be used on your PSV5000
System as follows:
I Select the Task,
II Click Edit,
III On the Task tab, use the Programming System
Type drop-down arrow to select PSV5000,
IV On the Handler Files tab, select (or create) a
Package File name,
V Click OK.
4. Run the duplicated Task on the PSV5000 System—
Note: If you have the option selected to Automatically Switch Programming
Systems, (System > Options > Automatically Switch ...) then you can skip
the next step.
4a. Close Task Manager and change the programming system
to PSV5000 System (System > Select Programming
System). Re-open the Task Manager.
4b. Select the duplicated job and click Run.
Note: The Package File must be taught if it is new.
TEST AFTER CREATING A PACKAGE FILE
After a Package File is created (described in the next few headings) or it
already exists for this package type and job, then this first article test
method is best when your job includes Laser Marking.
1. Create the PSV5000 job—
1a. In TaskLink, create a new job for PSV5000 Systems.
1b. Click Run (or Load) in TaskLink to start the CH700.
2. Run one device—
2a. In CH700, click Start.
2b. In the Setup window, select media options as usual.
2c. At the PSV5000 workspace set up the input and output
media as usual.
2d. Click Run > Run One.
Programmers that are
not used for a particular
job can be turned off in
the CH700 Start window.
