PSV5000 Owner’s Manual - 3 -
Symbols for Specific Models &
Options
The following symbols appear in the side bar next to paragraphs or
procedural steps that are limited to a specific model or piece of optional
equipment. If the symbol is next to a heading, the entire content under
that heading is limited to the equipment indicated.
This Symbol
Means…
Adjacent information is limited to this optional
equipment:
Tape-In Module (Tape Feeder)
Only Tape Output Systems
Only Auto‐Tray Feeder
Fiber Laser Marking System.
FlashCORE (FC) programmers
Lumen™X (LX) programmers
Preface ■ Precautions for Safe Operation
- 4 - Data I/O ■ 096-0465-001C
Precautions for Safe Operation
PSV5000 has many safety features designed to make the system safe
and efficient to operate. The system can be dangerous if the safety
precautions and features are ignored.
To avoid possible personal injury or damage to the equipment, observe
the following practices:
Precaution List
GENERAL PRECAUTIONS
Do not use the PSV5000 System for any purpose other than its
intended use.
Personal injury could be caused from high leakage electrical current
from the main power cable. An Earth (ground) connection is
essential before connecting power.
Do not operate the system if the safety doors and shields are not in
their normal operating positions.
Do not operate the system when any of the cabinet panels (sheet
metal) are removed.
Do not operate the PSV5000 System unless you have been
thoroughly trained and have read and understand the instructions
in this manual (or the Operator’s Manual), particularly those that
describe the system’s safety features (Safety Systems on page 12.)
Do not disable or attempt to defeat any of the safety features of this
system. Serious personal injury and equipment damage can occur if
any safety systems are disabled. If you suspect that a safety feature
of the system is damaged or malfunctioning, stop using the PSV5000
immediately and contact your local Data I/O Support representative.
Do not place any part of your body near moving machine parts.
REPAIR PRECAUTIONS
Only qualified personnel trained by Data I/O should install,
maintain, repair, or troubleshoot the PSV5000 Systems.
Do not operate a system while servicing, replacing, or adjusting any
component unless directed to do so in this manual. Make sure that
the system is properly shut down before servicing, replacing
components, or adjusting components.
Disconnect the external air before servicing pneumatic parts.
WARNING:
Pinch hazard.
The E-Stop does
not turn off air.
Socket
Actuators can
still move down
when an E-Stop
is pushed— and
even when
Safety doors, are
open.
Use caution.
■ Precautions for Safe Operation □ Jump Right In
PSV5000 Owner’s Manual - 5 -
OPTIONAL EQUIPMENT PRECAUTIONS
Use extra caution when using the Tape Input module (feeder) or
the Tape Output module options. The PSV5000 safety doors do not
fully enclose them. It is possible that hands, hair, or loose clothing
could get caught or pinched in these mechanisms.
Read and heed the laser vacuum filter disposal requirements
described later in this section (Laser Safety on page 27). Always
dispose of any other hazardous or residual by-products of the
production process in accordance with governing laws and
regulations.
Jump Right In
Thanks for reading about the safety symbols, notes, and icons. If your
PSV5000 System is already set up and you want to skip ahead:
Be safe —see Safety Systems on page 12.
Where’s the _____? —see Machine Components on page 19
How to run a job —see the separate PSV5000 Operator’s Manual.
What if it stops? —see Troubleshooting on page 131
What info is needed when I request service? -see next page.
Basic operating
instructions are in a
separate manual in hard
copy format as well as
PDF on the Handler
computer.
