Item Specification Power Control Box Folded aluminium fabrication located at top front of cabinet containing: 2 x 30 amp double pole power relays 1 x 30 amp motor power regulator 1 x 16 amp outlet socket (to motor unit) …

SPECIFICATION

Item Specification

Models DEK 265 machine, 220Volt -240Volt 50/60Hz. Part No.157491

DEK 265 machine, 100Volt -120Volt 60Hz. Part No.157490

Cabinet Material: High impact ABS R21 UL94 H&B Pinseal finish colour 0706

Height - 870mm

Width - 422mm

Depth - 600mm

Front control panel height - 500mm

Contaminated air intake height - 500mm

By-pass Cooling

Module

Contains the cooling air inlet and high-pressure air outlet to two stage silencer

assembly.

Vacuum Pump and

HEPA Module

Motors - Twin multi-stage by-passing cooling acoustic motors fitted with fail

stop carbon brushes.

Available

Voltages -

220Volt -240Volt, 50/60 Hz

100Volt -120Volt, 60Hz

Power - 2000 Watts

NOTE:

Motor watts shown are MAXIMUM input watts. However, in accord

with the specific requirements of the majority of International Approved

Agencies, rating labels on machines show MEAN operational watts,

being the average watts consumed during normal use,

i.e. 1000 watts MAX = 800 watts MEAN

2000 watts MAX = 1600 watts MEAN

Vacuum 1257 mm. Water gauge

Airflow Free air 49.6 L/sec

HEPA

Filtration

High efficiency particulate air filter 0.5 micron to 99.9975% efficiency

Third Stage Filter A 5-micron fabric filter is located between vacuum pump assembly and the activated

granular (ozone) filter

Ozone Filter Comprises a stainless steel bodied activated coconut shell granular filter containing

12.5 kg filter media

Pre-filter A 5-micron fabric filter is located between air in chamber and the activated granular

(ozone) filter

Air-in Chamber Powder coated mild steel contaminated air inlet receiving chamber secured to base of

cabinet

8 DEK Printing Machines Ltd Issue 3. Nov 00

DEK VACUUM AND FILTRATION UNIT SP08

SPECIFICATION

Item Specification

Power Control Box Folded aluminium fabrication located at top front of cabinet containing:

2 x 30 amp double pole power relays

1 x 30 amp motor power regulator

1 x 16 amp outlet socket (to motor unit)

1 x EMC mains filter

1 x 7 pin outlet socket (to front control panel)

2 x flying leads to rear panel

Internal Transfer

Pipework

A 52 mm bore wire-reinforced hose fitted with neoprene hose ends

Integral Silencer

Assembly

A 68 mm bore x 500 mm PVC acoustically lined transfer pipe coupled to the exhaust

muffler

Front Control Panel Comprising:

Displaying 7 digit motor run hours service meter

Motor speed controller 50% to 100%

Red standby neon indicator.

Green blinking remote control run indicator.

Fitted with flying lead and 7 pin plug to control box

Rear Control Panel Comprising:

1 x 16 amp chassis plug

1 x 16 amp double pole switch

1 x 13 amp fuse holder and fuse

1 x 2 pin remote chassis plug (for remote switching)

1 x 500 ma. fuse holder and fuse.

Cabinet Lid Recessed grey moulding (acoustically lined) tongue and grooved fixing at front, 3

screw fixing at rear with A4 size moulded tray

Grab Handles Powder coated 15mm solid bar aluminum front and rear

Noise Level 57dB

Weight 58Kg

Internal Cabinet

Temperature

41.5

Mains Lead 5 Meters x 1.5mm, black

Suction Hose 2 Meters x 38mm, EVA (Ethyl Vinyl Acetate)

Issue 3. Nov 00 DEK Printing Machines Ltd 9

DEK VACUUM AND FILTRATION UNIT SP08

SPECIFICATION

GENERAL SERVICING & MAINTENANCE INFORMATION

General The frequency of maintenance required will vary according to the usage of the

unit (measured in hours, see Sevice Meter) and the types of solvents used. This

can vary accordingly between periods of three to twelve months.

Filters To ensure that the vacuum/suction filtration unit always performs at peak

performance it is essential to replace the main carbon filter before twelve months

and sooner if non-water based solvents are used.

Vacuum Motors The special acoustic vacuum motors, 2 off, are fitted with auto-stop carbon

brushes, to protect the motors. The brush is designed to disengage the contact

between the carbon brush and the commutator. It is recommended that the

carbon brushes are inspected and/or replaced after a period of between

1000-1500 hours, see Service Meter. This will save any down-time should the

carbon brush autostop.

Service Meter A service meter is fitted to the front control panel showing the machine useage in

hours. The meter is provided as a reference as part of a routine maintenance

programme.

Hoses Clear flexible spiral interlocked E.V.A. hose. Crush resistant and durable,

requiring only visual inspection.

Cabinets The tough high-impact ABS cabinet requires little or no maintenance, other than

ensuring that the fixtures at the rear of the lid are always in place and that the unit

is situated on level ground.

Access Tools required: 1x No.3 Pozidrive Screwdriver

To gain access to the service items, by remove the cabinet lid as follows:

1. Unplug the unit from the mains supply.

2. Unplug the 24V remote switching connector.

3. Undo the 3 pozidrive headed screws at the rear of the lid.

4. Lift up the rear of lid until it clears the top edge of the cabinet.

5. Slide forward to disengage the tongue from the front recess (hidden).

6. Lift the lid from its position to expose all internal all internal components &

modules.

10 DEK Printing Machines Ltd Issue 3. Nov 00

DEK VACUUM AND FILTRATION UNIT SP08

GENERAL SERVICING & MAINTENANCE INFORMATION
