SP08 - 第8页
6 DEK Printing Machines Ltd Issue 3. Nov 00 DEK VACUUM AND FILTRATION UNIT SP08 DESCRIPTION Service Meter Speed Control Standby Indicator Run Indicator Figure 2 Operator Control Panel
Issue 3. Nov 00 DEK Printing Machines Ltd 5
DEK VACUUM AND FILTRATION UNIT SP08
DESCRIPTION
3rd Stage Filter
By-pass Cooling Assembly
HP Air Out
LP Air In
HEPA Filter
Pre-filter
Vacuum Pump Assembly
Ozone Filter
Cyclonic Entry for
High Pressure Air In
Figure 1 Layout of Internal Components
6 DEK Printing Machines Ltd Issue 3. Nov 00
DEK VACUUM AND FILTRATION UNIT SP08
DESCRIPTION
Service Meter Speed Control Standby Indicator Run Indicator
Figure 2 Operator Control Panel
Issue 3. Nov 00 DEK Printing Machines Ltd 7
DEK VACUUM AND FILTRATION UNIT SP08
DESCRIPTION
24V Supply
from DEK Machine
24V Fuse
Mains Fuse
On / Off Switch
Incoming Mains Supply
Chassis Plug
HP Air In
from DEK Machine
Exhaust from
HP Outlet
Silencers
Exhaust from
Motor Fans
Figure 3 Rear Connection Panel
