AV131 MAINTENANCE MANUAL 5.2 T ransf er Rail D79MEC- Y3-000-A 0 5.2- 1 5.2. Transfer Rai l D79MEC -Y3- 00 0-A0 5.2. 1 Transfer Rai l Unit No. N610061299A A No. Name T y p e 1. PCB pr esence detect ion P919T 2. PCB pr ese…

100%1 / 244
AV131
MAINTENANCE MANUAL
5.1 Insertion Head Unit
D79MEC-Y1-M00-A0
5.1-2
5.1.2 Insertion Unit Drive
Unit No. N610052015AA
No. Name Type
1. WH axis origin P914SA1
1.
AV131
MAINTENANCE MANUAL
5.2 Transfer Rail
D79MEC-Y3-000-A0
5.2-1
5.2. Transfer Rail
D79MEC-Y3-000-A0
5.2.1 Transfer Rail
Unit No. N610061299AA
No. Name Type
1. PCB presence detection P919T
2. PCB presence detection P919T
3. Rail up/down cylinder return detection D-C73
4. Rail up/down cylinder traverse detection D-C73
1.
2.
3.
4.
AV131
MAINTENANCE MANUAL
5.2 Transfer Rail
D79MEC-Y3-000-A0
5.2-2
