AV131 MAINTENANCE MANUAL 5.2 T ransf er Rail D79MEC- Y3-000-A 0 5.2- 2
AV131
MAINTENANCE MANUAL
5.2 Transfer Rail
D79MEC-Y3-000-A0
5.2-1
5.2. Transfer Rail
D79MEC-Y3-000-A0
5.2.1 Transfer Rail
Unit No. N610061299AA
No. Name Type
1. PCB presence detection P919T
2. PCB presence detection P919T
3. Rail up/down cylinder return detection D-C73
4. Rail up/down cylinder traverse detection D-C73
1.
2.
3.
4.
AV131
MAINTENANCE MANUAL
5.2 Transfer Rail
D79MEC-Y3-000-A0
5.2-2
AV131
MAINTENANCE MANUAL
5.3 PCB Transfer Unit
D79MEC-Y3-200-A0
5.3-1
5.3. PCB Transfer Unit
D79MEC-Y3-200-A0
5.3.1 PCB Transfer Unit
Unit No. N610060945AA
No. Name Type
1. Transfer arm feed detection P914S1
2. Transfer arm feed slowdown detection P914S1
3. Transfer arm reverse detection P914S1
4. Positioner cylinder reverse detection D-A73
5. Positioner cylinder forward detection D-A73
1.
3.
2.
4.
5.
