AV131 MAINTENANCE MANUAL 5.7 Par t Supply Unit D79MEC- Y5-000-A 0 5.7- 4
AV131
MAINTENANCE MANUAL
5.7 Part Supply Unit
D79MEC-Y5-000-A0
5.7-3
5.7.3 Transfer Chuck
Unit No. N610052073AA
No. Name Type
1. 26 / 52 mm changeover detection sensor EE-SX871
2. T axis origin detection sensor P914SA1
1.
2.
Dog
View on arrow A
A
AV131
MAINTENANCE MANUAL
5.7 Part Supply Unit
D79MEC-Y5-000-A0
5.7-4
AV131
MAINTENANCE MANUAL
5.8 Cutter Unit
D79MEC-Y5-200-A0
5.8-1
5.8. Cutter Unit
D79MEC-Y5-200-A0
5.8.1 Tape Cutter
Unit No. N610052014AA
No. Name Type
1. Feeder detection sensor E32-DC200E
2. Feeder dumper cylinder reverse limit D-A73
3. Feeder dumper cylinder forward limit D-A73
4. Component detection sensor FT-SFM2SV2
1.
2.
3.
4.
