5.8. Cutter Unit
D79MEC-Y5-200-A0
5.8.1 Tape Cutter
Unit No. N610052014AA
No. Name Type
1. Feeder detection sensor E32-DC200E
2. Feeder dumper cylinder reverse limit D-A73
3. Feeder dumper cylinder forward limit D-A73
4. Component detection sensor FT-SFM2SV2
1.
2.
3.
4.
