10.1. Precautions in Disposing of Gas Dampers
D79MEC-A1-060-A0
10.1.1 Removing Gas Dampers
This machine utilizes gas dampers for opening/closing the cover.
Since the gas dampers include high pressure gas, do not disassemble nor throw them in fires.
Before disposing of them, be sure to degas the cylinder.
Location
Removing Procedure
Step Operation Result, reference drawing, etc.
1.
Remove the bolts securing the gas
damper to detach the gas damper.
2.
Using a drill of the specified
diameter, punch a hole at the
position shown in the drawing to
degas the gas damper.
Do not discard it until degassing is
completed.
Bolt
Drill
AV131
MAINTENANCE MANUAL
10.1 Precautions in Disposing of Gas Dampers
D79MEC-A1-060-A0
10.1-2
AV131
MAINTENANCE MANUAL
10.2 Synthetic Resin Parts
D79MEC-A1-020-A0
10.2-1
10.2. Synthetic Resin Parts
D79MEC-A1-020-A0
The AV131 employs the synthetic resin parts listed in the table below.
Parts List
Name Product code Process Constituent
Weight (g)
Quantity Remarks
FRONT
COVER
N210081417AA Cut
PC
Polycarbonate
1980 1
Main unit
cover
DOOR
COVER
N210072760AA Cut
PC
Polycarbonate
2715/1357.5
2 (120 inputs)
1 (60 inputs)
Z axis
cover
COVER N210071571AA Cut
PC
Polycarbonate
607/0
2 (120 inputs)
0 (60 inputs)
Z axis
cover
GUIDE RAIL 102070710001 Molded POM 1960/950
28 (120 inputs)
14 (60 inputs)
Z axis
GUIDE RAIL 102070710101 Molded POM 280/140
4 (120 inputs)
2 (60 inputs)
Z axis
GUIDE 1046907060 Molded
PC
Polycarbonate
1500/750
10 (120 inputs)
5 (60 inputs)
Z axis
HOSE 1041325026 Molded
(Olefinic resin +
rubber)
190 1 Scrap duct
HOSE 1041325027 Molded
(Special-formula
vinyl chloride)
430 1 Scrap duct
SOCKET 104132502401 Cut PVC 140 1 Scrap duct
SOCKET 104132502501 Cut PVC 240 1 Scrap duct
5 1 set 1
PLATE 102073301101 Molded PBT
600 (120 inputs)
300 (60 inputs)
Max. 120 sets
(120 inputs)
60 sets (60 inputs)
Common to
feeders
5 1 set 1
PLATE 102073301201 Molded PBT
600 (120 inputs)
300 (60 inputs)
Max. 120 sets
(120 inputs)
60 sets (60 inputs)
Feeder
26 mm
11 1 set 1
FRAME 1020733015 Molded PA
1320 (120 inputs)
660 (60 inputs)
Max. 120 sets
(120 inputs)
60 sets (60 inputs)
Feeder
26 mm
22 1 set 1
FRAME 1020733017 Molded PA
2640 (120 inputs)
1320 (60 inputs)
Max. 120 sets
(120 inputs)
60 sets (60 inputs)
Feeder
26 mm
17 1 set 1
SLIDE
BLOCK
102073100301 Molded PBT
2040 (120 inputs)
1020 (60 inputs)
Max. 120 sets
(120 inputs)
60 sets (60 inputs)
Feeder
26 mm
11 1 set 1
FRAME 1020731015 Molded PA
1320 (120 inputs)
660 (60 inputs)
Max. 120 sets
(120 inputs)
60 sets (60 inputs)
Feeder
52 mm
