AV131
MAINTENANCE MANUAL
4.1 Control System Configuration
D79MEC-14-020-A0
4.1-22
I / O MAP OUTPUT
Board
connector
Address No. Name bit Note
113 00302: Part waste blow valve: OUT 0 Option
114 1
115 2
116 3
117 4
118 5
119 6
#3_CN7 00E1
120 7
137 04230: Rail open/close valve (BSF-V): OUT 0
138
04231: PCB conveyor motor reverse return
(BSF-V): OUT
1
139
04232: PCB conveyor motor right return
(BSF-V): OUT
2
140
04233: PCB conveyor motor brake (BSF-V):
OUT
3
141 04234: Vacuum valve (BSF-V): OUT 4
142 04235: Vacuum suction valve up (BSF-V): OUT 5
143
04236: Vacuum suction valve down (BSF-V):
OUT
6
#4_CN5 0120
144 7
145
03334: Automatic width adjustment start signal
(SC → CONV): OUT (OP)
0 Option
146 1
147 2
148 3
149 4
150 5
151 6
#4_CN7 0121
152 7
153 04256: Conveyor belt motor signal: OUT (OP) 0 Option
154 1
155 2
156 3
157 4
158 5
159 6
#4_CN9 0122
160 7
161
Group empty signal (SC → LM)
0
162
Loader empty signal (SC → LM)
1
163
Count up signal (SC → LM)
2
164
Main body empty signal (SC → LM)
3
165 4
166 5
167 6
#4_CN6 0123
168 7
#22_CNMC3 329 Vacuum pump ON 0
#22_CNMC2 330 1
#22_Inside 331 Main circuit ON 2
#22_CNBK1 332 3
#22_CNBK2 333 4
#22_Inside 334 Safety relay reset 5
#22_Inside 335 Motor 24V power ON 6
#22_Inside
00A0
336 Instantaneous stop detection reset 7
AV131
MAINTENANCE MANUAL
4.1 Control System Configuration
D79MEC-14-020-A0
4.1-23
I / O MAP OUTPUT
Board
connector
Address No. Name bit Note
337 00312: PCB supply CYL signal 0
#22_CNXOUT
338 1
339 Under maintenance ON 2
340 Not used 3
341 Not used 4
#22_ －
342 Not used 5
#22_CNMC4 343 Spare input 6
#22_CNMC5
00A2
344 Spare input 7
#22_CN00 345 00311: Loader stocker rotation signal 0
#22_CN01 346 00312: Unloader stocker rotation signal 1
347 2
#22_-
348 3
#22_CN01 349 00314: Push arm CYL signal 4
350 5
351 6
#22_-
00A3
352 7
353 For direct start monitor 0
354 For direct start monitor 1
355 For direct start monitor 2
356 For direct start monitor 3
357 For direct start monitor 4
358 For direct start monitor 5
359 For direct start monitor 6
#23_CN5 05E0
360 For direct start monitor 7
361 For direct start monitor 0
362 For direct start monitor 1
363 For direct start monitor 2
364 For direct start monitor 3
365 For direct start monitor 4
366 For direct start monitor 5
367 For direct start monitor 6
#23_CN7 05E0
368 For direct start monitor 7
Maintenance light 1 0
Maintenance light 2 1
Maintenance light 3 2
Maintenance light 4 3
4
5
6
#23_CN9 805E2
7
AV131
MAINTENANCE MANUAL
4.1 Control System Configuration
D79MEC-14-020-A0
4.1-24
