23 Placement heads SIPLACE TwinStar (TH) SIPLACE T winSt ar With component came ra type 33 (fine pitch camera) With component camera type 25 (flip chip camera) Component range a a) Please note that the placeable componen…

Placement heads

SIPLACE MultiStar (CPP)

Increased performance and flexibility

The SIPLACE Multistar is the

perfect SIPLACE solution:

• In an increasingly complex

production environment

• For an increasing diversity

of setup and production

strategies

• For a wide spectrum of

components

• For frequent product

changeovers.

It is even possible to place

larger components without a

noticeable drop in perfor-

mance. The SIPLACE Mul-

tistar is perfectly designed for

integration into a flexible and

speed-optimized production

environment.

One head for all applica-

tions

• The SIPLACE MultiStar

offers top flexibility

• It combines

Collect&Place mode with

Pick&Place mode

One head supports three

placement modes:

Elimination of bottlenecks

• A wider component spec-

trum

• Optimum performance uti-

lization

• More feeder module

tracks for the TwinStar

• Improved throughput due

to perfect line utilization

• More products in one set-

up family

Throughput

• Up to 23,500 components/

h benchmark value

• Up to 19,000 components/

h IPC 9850 performance

Collect&Place mode

Pick&Place mode

Mixed mode

Placement heads

SIPLACE TwinStar (TH)

SIPLACE TwinStar

With component camera type 33

(fine pitch camera)

With component camera type 25

(flip chip camera)

Component range

a) Please note that the placeable component range is also affected by the pad geometry, the customer-specific standards,

the component packaging tolerances and the component tolerances.

0402 to SO, PLCC, QFP, BGA, special

components, bare dies, flip-chips

0201 to SO, PLCC, QFP, sockets,

plugs, BGA, special components, bare

dies, flip-chips, shields

Component specs

Max. height

Min. lead pitch

Min. lead width

Min. ball pitch

Min. ball diameter

Min. dimensions

Max. dimensions

Max. weight

b) If the MultiStar and TwinStar are combined in the same placement area, the maximum component height may be re-

stricted.

c) If standard nozzles are used

25 mm (higher available on request)

0.3 mm

0.15 mm

0.35 mm

0.2 mm

1.0 mm x 0.5 mm

55 mm x 45 mm (single measurement)

For use with two nozzles (multiple mea-

surement)

50 mm x 50 mm or

69 mm x 10 mm

For use with one nozzle

85 mm x 85 mm or

125 mm x 10 mm

up to 200 mm x 125 mm (with restric-

tions)

100 g

25 mm (higher available on request)

0.25 mm

0.1 mm

0.14 mm

0.08 mm

0.6 mm x 0.3 mm

16 mm x 16 mm (single measurement)

55 mm x 55 mm (multiple measure-

ment)

100 g

Programmable set-down

force

1.0 N - 15 N

2.0 N - 30 N

d) SIPLACE High-Force Head.

1.0 N - 15 N

2.0 N - 30 N

Nozzle types

e) Over 300 different nozzles and 100 gripper types are available, with an extensive nozzle database available online.

5xx (standard)

4xx + adapter

8xx + adapter

9xx + adapter

Gripper

5xx (standard)

4xx + adapter

8xx + adapter

9xx + adapter

Gripper

Nozzle spacing for P&P

heads

70.8 mm 70.8 mm

X/Y accuracy

± 26 µm / 3± 35 µm / 4 ± 22 µm / 3± 30 µm / 4

Angular accuracy ± 0.05° / 3± 0.07°/ 4 ± 0.05° / 3± 0.07° / 4

Illumination level 6 6

Possible illumination level

settings

256

f) The SIPLACE benchmark value is measured during the machine acceptance tests. It corresponds to the conditions set

out in the SIPLACE scope of service and supply.

Placement heads

Nozzle changer

Description

Nozzle changers increase

the flexibility of the placement

heads when it comes to pro-

cessing different compo-

nents. The nozzle

configuration can be rapidly

adjusted to changing place-

ment jobs. Precisely defined

positions and perfect nozzle

seat in the garage ensure

minimum radial eccentricity

on the placement head.

The nozzle changer for the

MultiStar is fitted with a mon-

itoring device. This checks

whether the nozzle magazine

is seated correctly on the

mount. In addition, the nozzle

changers recognize whether

the magazines are for 1xx,

20xx or 28xx nozzles by the

code.

Nozzle changer for the SIPLACE MultiStar

Magazine for two

standard nozzles

Magazine for one special nozzle, gripper

Nozzle changer for the SIPLACE TwinStar

1 magazine for 9 nozzles

of type 28xx

5 magazine for 12 nozzles of

type 20xx

6 magazines for 20 nozzles of

type 40xx

Nozzle changer for the SIPLACE SpeedStar

4 magazines for 20 nozzles of

type 40xx

1 magazine for 9 nozzles

of type 28xx

3 magazines for 12 nozzles

of type 20xx
