F
eeder Station Ass’y
19 Page
SAMSUNG TECHWIN
Part Photo
J1301354
THROTTLE VALVE STRAIGHT
J6701031A AIR CYLINDER [WTR2530]
J1301364 ELBOW FITTING [KQ2L08-03PL8-03]
J6711028A ELBOW FITTING [KQ2L04-01]
J3212014A PHOTO SENSOR [EE-SY671]
J6711059A STRAIGHT FITTING [KQ2H12-04]
F
eeder Station Ass’y
20 Page
SAMSUNG TECHWIN
Part Photo
J6711141A
STRAIGHT FITTING [M-5AU-4]
J7158003B MANIFOLD
J6711155A LIGHT COUPLING [CPS15M-8B]
J9058040B (CP-60)MANIFOLD ASSY(ST)
J6711156A HOSE NIPPLE [M-5H-4](DC용)
D
C Feeder Base Ass’y
21 Page
SAMSUNG TECHWIN
Part Photo
J7157037B BLOCK-SUPPORT-R
J7157059B BLOCK-SUPPORT-L
