S ide Frame Ass’y 35 Page SAMSUNG TECHWIN Part Photo J6119003A SUPPORT UNIT-Y MOTOR J7054068E SENSOR DOG-Y R.H J6601077A SUPPORT UNIT-Y END J7054069C SENSOR DOG-Y L.H J7054022B CLAMP-MOTOR BRACKET J7054080E MOTOR BRACKET…
S
ide Frame Ass’y
34 Page
SAMSUNG TECHWIN
Part Photo
J7254016D INNER GUIDE-MAT
J7354008B CUSHION-Y
J7254017A OUTTER GUIDE
J9080521A X MOTOR ASSY[CP60HP-TH-SV-0O-1]
J7254027B CUSHION
S
ide Frame Ass’y
35 Page
SAMSUNG TECHWIN
Part Photo
J6119003A SUPPORT UNIT-Y MOTOR
J7054068E SENSOR DOG-Y R.H
J6601077A
SUPPORT UNIT-Y END
J7054069C SENSOR DOG-Y L.H
J7054022B CLAMP-MOTOR BRACKET
J7054080E MOTOR BRACKET-Y
S
ide Frame Ass’y
36 Page
SAMSUNG TECHWIN
Part Photo
J7154118C CAP-NUT
J7354003B CUSHION-Y MOTOR
J7154119C END CAP-NUT
J7354004B CUSHION-Y TAIL
J7154120C END CAP-NUT-LONG
