C arrier Ass’y 46 Page SAMSUNG TECHWIN Part Photo J7055533A EXTENSION SPRING J7155459C THETA-MOTOR BKT J7055579A SUPPORT PULLEY J7155460B IDLER BEARING RIGHT J7155229A WASHER PRECISION J7155462B IDLER BEARING LEFT
C
arrier Ass’y
45 Page
SAMSUNG TECHWIN
Part Photo
J6711054A BARBED PORTS FOR 11618ID FLEXIBLE TUBE
J7055183C BALL SPLINE ASSY
J6712004A
PLUG PLASTIC 10-32UNF
J7055187A SPRING GUIDE PIN
J6713024A
PRESSURE TUBING POLYURETHANE 116
J7055189A PINION GEAR
C
arrier Ass’y
46 Page
SAMSUNG TECHWIN
Part Photo
J7055533A EXTENSION SPRING
J7155459C THETA-MOTOR BKT
J7055579A SUPPORT PULLEY
J7155460B IDLER BEARING RIGHT
J7155229A WASHER PRECISION
J7155462B IDLER BEARING LEFT
C
arrier Ass’y
47 Page
SAMSUNG TECHWIN
Part Photo
J7155465A
BELT TENSION BAR SPINDLE
J7155471B PULLEY IDLE SMALL
J7155466B HOUSING-SINGLE
J7155472B PULLEY MOTOR
J7155470B PULLEY IDLE
J7155480D Z-ROD CAP
