CP63HP Technical Reference_CS_Ver - 第58页
M oving Transport Rail Ass’y 58 Page SAMSUNG TECHWIN Part Photo J7153074A IDLE PULLEY J7153075A SPACER-PULLEY
M
oving Transport Rail Ass’y
57 Page
SAMSUNG TECHWIN
Part Photo
J7053097B SCREW-PULLEY
J7153064A PULLEY-CONV MOTOR
J7053247A SCREW-PULLEY
J7153065B BUSH-SPRING
J7053248A TENSION SLIDER
J7153073A IDLE PULLEY-LARGE
M
oving Transport Rail Ass’y
58 Page
SAMSUNG TECHWIN
Part Photo
J7153074A IDLE PULLEY J7153075A SPACER-PULLEY
1
4
3
2
O
peration Ass’y
59 Page
SAMSUNG TECHWIN
2
3
