1 Introduction User M anual SIPLACE F5 H M 1.8 Revisions since 03/2006 edition Software Version SR.408.xx 03/2006 US Edition 18 PCB barcod e 7.4 Ceramic su bstrate c enterin g 7.5 Flip-chi p vision m odule for the P ick&…
User Manual SIPLACE F5 HM 1 Introduction
Software Version SR.408.xx 03/2006 US Edition 1.7 Revisions since 01/2001 edition
17
1.7 Revisions since 01/2001 edition
1
1
1.8 Revisions since 03/2006 edition
1
New or modified Chapter/section
Warning labels on the machine 2.1.5
Additional warning labels for the NAFTA region 2.1.6
Safety instructions for processing capacitors based on powdered
metal
2.1.15
Feeder module 10.1.1
Safety instructions for processing capacitors based on powdered
metal
10.1.2
12 mm S feeder for capacitors based on powdered metal, model
C/D
10.2.5
12 mm S feeder for capacitors based on powdered metal, model E 10.2.6
Optical centering with the multi-color PCB camera 11.5.6
Fine calibration 11.13
New or modified Chapter/section
Introduction
1
Operational safety 2
Description of the machine 3.1
Performance data 3.2
The line concept 3.3
Technical data – Ratings 3.5
Dimensions and weight of the placement system 3.6
Controls 3.7
Placement heads 3.9
PCB dual conveyor 3.12
Adjusting the component trolley to another PCB transport height 4.3
Tasks on the machine 5
Feeder modules 6.1
Technical data for the S feeder modules 6.2
Component trolley 6.3
1 Introduction User Manual SIPLACE F5 HM
1.8 Revisions since 03/2006 edition Software Version SR.408.xx 03/2006 US Edition
18
PCB barcode
7.4
Ceramic substrate centering 7.5
Flip-chip vision module for the Pick&Place head 7.8
Coplanarity laser module 7.9
DCA vision camera 7.10
SIPLACE productivity lift 7.12
PCB support 7.13
New or modified Chapter/section
User Manual SIPLACE F5 HM 1 Introduction
Software Version SR.408.xx 03/2006 US Edition 1.9 Abbreviations
19
1.9 Abbreviations
1
1
PA 1 Placement area 1
CO 1 Component 1
C&P 1 Collect&Place 1
C&P12 1 Collect&Place head with 12 segments 1
C&P6 1 Collect&Place head with 6 segments 1
DCA 1 Direct Chip Attach 1
DC 1 Dual conveyor 1
EGB 1 Electrostatically-sensitive group of components 1
ESD 1 Electrostatic sensitive device 1
SC 1 Single conveyor 1
FC 1 Flip chip 1
WT 1 Waffle-pack tray 1
WTC 1 Waffle-pack tray carrier 1
GND 1 Ground 1
IC 1 Integrated circuit 1
PCB 1 Printed circuit board 1
SMR 1 Start of measuring range 1
EMR 1 End of measuring range 1
MMR 1 Middle of measuring range 1
MC 1 Machine controller 1
OSC 1 Odd shaped components 1
P&P 1 Pick&Place 1
SMD 1 Surface mounted device 1
SC 1 Station computer 1
VS 1 Vision system 1
WLAN 1 Wireless Local Network 1
WPC 1 Waffle-pack changer 1
