7.5 Ceramic substrate centering
7.5.1 General
The ceramic substrate can be centered either mechanically or optically.
The position of the fiducials on the ceramic substrates can be detected either with
– the sub-gantry PCB camera with normal lighting that is fitted as standard, or
– using the multi-color PCB camera (option).
7.5.2 Mechanical centering
7.5.2.1 General
Mechanical substrate centering is used to lock ceramic substrates firmly in position in the X and
Y directions in such a way that the material is not damaged. Ceramic substrates can also be
placed right up to the edge.
7.5.2.2 Assembling and dismantling the ceramic substrate centering unit
PLEASE NOTE 7
The ceramic substrate centering unit must only be assembled and dismantled by service engi-
neers. 7
User Manual SIPLACE F5 HM 7 Options
Software Version SR.408.xx 03/2006 US Edition 7.5 Ceramic substrate centering
193
Fig. 7.5 - 1 Ceramic substrate centering (side view)
(1) Mechanical ceramic substrate centering
(2) Stop
(3) Ball bearing
(4) Centering slide
(5) Proximity switch connecting cable
(6) Compressed air connection
7.5.2.3 Maintenance
– Clean and grease the ball race in the X axis centering unit.
– If necessary, check that the pneumatic driving mechanism is running smoothly.
– The conveyor should be maintained as described in the maintenance instructions.
7 Options User Manual SIPLACE F5 HM
7.5 Ceramic substrate centering Software Version SR.408.xx 03/2006 US Edition
194
7.5.3 Technical data
7
7
Substrate format 50 x 50 mm² to 100 x 180 mm²
Substrate thickness 0.5 mm to 1.5 mm
Substrate model Unscribed (without problems)
Scribed (requires testing)
Support on the conveyor 2.5 mm
Optical centering: field of view of the PCB vision module
Type of illumination for light pastes:
Type of illumination for dark pastes and close spacing to
adjacent structures (> 1 mm)
5.7 x 5.7 mm²
PCB camera (standard)
Multicolor camera (option)
(4 illumination levels to be selected)
Fiducial criteria See PCB vision module position
detection
Mechanical centering:
X/Y centering accuracy ± 0.07 mm / 4 sigma
PCB underside clearance 12 mm
Compressed air connection 0.55 MPa (5.5 bar)
