1.9 Abbreviations

PA 1 Placement area 1

CO 1 Component 1

C&P 1 Collect&Place 1

C&P12 1 Collect&Place head with 12 segments 1

C&P6 1 Collect&Place head with 6 segments 1

DCA 1 Direct Chip Attach 1

DC 1 Dual conveyor 1

EGB 1 Electrostatically-sensitive group of components 1

ESD 1 Electrostatic sensitive device 1

SC 1 Single conveyor 1

FC 1 Flip chip 1

WT 1 Waffle-pack tray 1

WTC 1 Waffle-pack tray carrier 1

GND 1 Ground 1

IC 1 Integrated circuit 1

PCB 1 Printed circuit board 1

SMR 1 Start of measuring range 1

EMR 1 End of measuring range 1

MMR 1 Middle of measuring range 1

MC 1 Machine controller 1

OSC 1 Odd shaped components 1

P&P 1 Pick&Place 1

SMD 1 Surface mounted device 1

SC 1 Station computer 1

VS 1 Vision system 1

WLAN 1 Wireless Local Network 1

WPC 1 Waffle-pack changer 1

1 Introduction User Manual SIPLACE F5 HM

1.9 Abbreviations Software Version SR.408.xx 03/2006 US Edition

User Manual SIPLACE F5 HM 2 Operational safety

Software Version SR.408.xx 03/2006 US Edition 2.1 Safety instructions

2 Operational safety

2.1 Safety instructions

2.1.1 Conventions for the use of hazard symbols

This User Manual contains notes that must be observed to guarantee your personal safety and to

avoid damage to equipment. These notes are highlighted by warning triangles and are indicated

as follows according to the level of risk:

DANGER or

as used in this User Manual means that death, severe injury or considerable damage to equip-

ment

will

occur if the danger instructions are not followed.

WARNING or

as used in this User Manual means that death, severe injury or considerable damage to equip-

ment

may

occur if the warning instructions are not followed.

CAUTION or

as used in this User Manual means that slight injury or damage to equipment may occur if the

caution instructions are not followed.

NOTE

as used in this User Manual provides information on the product or indicates a part of the User

Manual that requires particular attention.

2.1.2 Qualified personnel

Qualified or adequately trained personnel means that these people are familiar with the setting

up, operation and preventive maintenance of automatic placement systems and add-on devices

and are suitably qualified, e.g.

– have been trained, instructed or authorized to switch on and off, isolate, earth and identify

electrical circuits and system components in accordance with normal safety standards.

– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-

cordance with normal safety standards.

– have received first aid training.
