User Manual SIPLACE F5 HM 2 Operational safety
Software Version SR.408.xx 03/2006 US Edition 2.1 Safety instructions
23
2.1.5.1 General
Æ The operational safety of SMD automatic placement systems can be guaranteed only if the
system is used as prescribed and in accordance with the instructions in the User/Service
Manuals.
Æ Always follow any safety regulations specific to your country.
Æ Make sure that the warning labels are always clearly identifiable and always easily readable.
Æ Replace any damaged warning or notice labels. Replace any labels that are missing.
Æ The machine key for releasing the covers on the machine must be kept in a safe place where
it is only accessible to qualified personnel.
PLEASE NOTE
The machine owner, and only the machine owner, is responsible for the safekeeping of the
machine key and for ensuring that it is handed over to authorized persons. 2
Æ If it is necessary to work on the machine and you do not have adequately trained personnel
within your operation, always call in a SIEMENS service engineer. SIEMENS will not accept
liability for any damage or consequential damage that is the result of incorrect work.
Æ If particularly hazardous situations are identified while the machine is in use, the machine
owner must immediately notify the manufacturer in writing so that appropriate action can be
taken to reduce the potential danger.
WARNING
In spite of all the safety precautions taken by the manufacturer, failure to use the system as pre-
scribed can result in severe physical injury (e.g. from the moving gantry or lifting table) and/or con-
siderable damage to equipment. For the machine to be safe, it must be used correctly by qualified
personnel and all warnings must be observed. Some work on the machine (e.g. setting up) re-
quires training that goes beyond the scope of this Manual. 2
2
2
2
2.1.5.2 Safety of operators and other persons
Æ Machine operators must only carry out work for which they have been adequately trained and
with which they are totally familiar.
2 Operational safety User Manual SIPLACE F5 HM
2.1 Safety instructions Software Version SR.408.xx 03/2006 US Edition
24
Æ NEVER open one of the protective covers if you are not totally familiar with the use and func-
tioning of the machine! Do not open the protective covers during operation unless you are told
to do so in this Manual or in the station software dialog.
Æ NEVER place your head or arms in the gantry and lifting table traveling range while the station
is switched on!
Æ For your own safety, wear work clothes that conform to the guidelines of the professional as-
sociation, i.e. no wide sleeves etc.
Æ Reduce the risks by not wearing scarves, chains or ties at your work post.
Æ People with long hair must wear a protective head covering.
WARNING 2
The system is electrically driven. When electrical devices are in use, certain parts carry danger-
ous voltage levels.
Æ Switch off at the main switch and disconnect the placement system from the power supply
before carrying out any work on live components.
Æ Lock the systems as described in Section 2.9, page 63.
There is a risk of death, severe injury and/or considerable damage to equipment if these instruc-
tions are not followed.
2.1.5.3 Safety of plant and equipment
Æ Never make changes, however minor, unless you are totally aware of the effect they will have
on the overall functioning of the system.
Æ The stations must always be set up, retooled and maintained by appropriately trained person-
nel.
Æ Only use SIEMENS original spare parts and authorized accessories. The use of other parts
will affect safety and will invalidate the liability for any consequential damage.
Æ Do not make modifications to the safety equipment. In particular, NEVER deactivate circuit-
breakers or remove safety devices.
2
2
2.1.6 Safety instructions for laser units
Permission to operate components that are classified as lasers is withdrawn if
– mechanical damage to the unit is observed, or
– any work is done on the mechanical or electrical parts of the unit. Even damaged or miss-
ing screw locking paint on laser components (e.g. cover plates, fasteners, adjusting po-
tentiometer) counts as work.
User Manual SIPLACE F5 HM 2 Operational safety
Software Version SR.408.xx 03/2006 US Edition 2.1 Safety instructions
25
– Only SIEMENS service engineers, or the machine owner's service engineers who have
been trained by SIEMENS are allowed to replace laser components.
– Repairs to laser units are carried out at the SIEMENS factory exclusively.
2.1.7 Important notes on environmentally-friendly disposal of materials
and components
SIPLACE systems are manufactured using only materials and parts that can be easily separated
and disposed of in an environmentally-friendly way. Hazardous materials are not necessary for
the installation, dismantling or operation of the system.
PLEASE NOTE 2
The owner of the system has sole responsibility for the proper environmentally-friendly disposal
of machines, working materials, consumables and wear parts.
Æ Please observe your national statutory provisions for waste disposal and environmental pro-
tection.
2.1.8 Important notes on warning labels
The warning labels are made from soft PVC film, and are abrasion-proof, light-fast and resistant
to water and weathering. 2
WARNING 2
– Do not use abrasive cleaners or solvents for cleaning warning labels.
– Replace any damaged or illegible warning labels.
