User Manual SIPLAC E F5 HM 2 Operational safety Software Vers ion SR.408.xx 03/2006 U S Edition 2.2 Warning labels 39 2 2 2 2 2 2 2 2 2 2 2 Pos. 5 in Fig. 2.2 - 7 2 Pos. 6 i n Fig. 2.2 - 7 , page 29 for th e warn ing la …

100%1 / 230
2 Operational safety User Manual SIPLACE F5 HM
2.2 Warning labels Software Version SR.408.xx 03/2006 US Edition
38
2
Pos. 2 in Fig. 2.2 - 7 2
2
Pos. 3 in Fig. 2.2 - 7
on the terminal blocks 2
2
Pos. 4 in Fig. 2.2 - 7
2
Warning
High voltage can cause
severe
injury or death
Service in this area must be performed by
authorized personell only
Switch off main electrical and pneumatic
switches, remove from main power
Operating machinery
can
crush and mutilate limbs
User Manual SIPLACE F5 HM 2 Operational safety
Software Version SR.408.xx 03/2006 US Edition 2.2 Warning labels
39
2
2
2
2
2
2
2
2
2
2
2
Pos. 5 in Fig. 2.2 - 7
2
Pos. 6 in Fig. 2.2 - 7
, page 29 for the warning labels on the basic machine
Use only approved feeders, labeled
as shown below, when feeding
capacitors based on metal-powder
(e.g. tantalum).
Fire Hazard
Can cause death, serious injury
or property damage
Approved for
capacitors based on
metal-powder
Freigegeben für
Kondensatoren auf
Metallpulver-Basis
WARNING
2 Operational safety User Manual SIPLACE F5 HM
2.2 Warning labels Software Version SR.408.xx 03/2006 US Edition
40
Sticker on feeder module (enlarged)
DANGER 2
Capacitors based on metal-powder, such as tantalum capacitors, may only be processed with
feeder modules that are identified with this sticker. 2
2.2.3 Warning label "Danger of crushing" on the component trolley
2
Warning label "Danger of Crushing" (number per component trolley: 2)
2
Fig. 2.2 - 8 Warning label Danger of crushing on the component trolley
Warning label Danger of crushing, item no. 00343357-01
2
2
2
WARNING DANGER OF CRUSHING!
Do not place your hands in the danger area
when lowering the component feeder table.
DANGER OF CRUSHING!
