N7202A030B - 第332页
44-B 交 換 台車駆 動部 (切替仕様):NPM-Ｄ Feeder Cart D rive Unit(Changing Specification):NPM-D パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N6 10 112 80 9A A ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O145 ( KN610112809AA-09-2 )
Ref
No.
Remarks
R
1
Q'ty
44-A
交
換
台車駆
動部
(切替仕様):NPM-Ｄ
Feeder Cart Drive Unit(Changing Specification):NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610112809AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
1
1 N210091111AC
PLATE
1
2 N210103084AB
PLATE
1
3 N210091113AA
GUIDE
1
4 N210093809AC
GUIDE
1
5 N210105774AD
GUIDE
1
6 N210103086AD
GUIDE
1
7 N210103087AC
PLATE
1
8 N210134721AB
COVER
1
9 N210103101AC
COVER
2
10 N210103092AC
BRACKET
1
11 N210112902AD
NUT-PLATE
1
12 N210091006AA
COVER
1
13 N210126107AA
COVER
1
14 N210134722AB
COVER
1
15 N210134725AB
BRACKET
1
16 N210126108AA
STOPPER
1
17 N610078705AA
SPACER
2
18 N510038787AA 3382330-50120
SWITCH
1
19 N510040005AA
S
D4N-9122
SPACER
2
20 N510009576AA 3382330-40020
PIN
6
21 KXF0CXHAA00 1017003-40008
SCREW
14
22 N510018280AA
Cross recessed Truss head machine screw M4X6-4.8 A2S (Trivalent)
BOLT
4
23 N510017555AA
SSS 003 Hexagon socket button head screw M6X12-10.9 A2J (Trivalent)
SPACER
2
24 N510020086AA 3382330-40050
VALVE
1
25 N510055190AA 4GA130-M5-A2NS-FL432737-3-ST
SCREW
2
26 N510018243AA
Cross recessed Truss head machine screw M3X20-4.8 A2S (Trivalent)
TAPE
2
27 N510012192AA #500AS20
O144
--
( KN610112809AA-09-1 )
44-B
交
換
台車駆
動部
(切替仕様):NPM-Ｄ
Feeder Cart Drive Unit(Changing Specification):NPM-D
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610112809AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O145
( KN610112809AA-09-2 )
Ref
No.
Remarks
R
1
Q'ty
44-B
交
換
台車駆
動部
(切替仕様):NPM-Ｄ
Feeder Cart Drive Unit(Changing Specification):NPM-D
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610112809AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
1
1 N210091233AA
SHAFT
1
2 N210091107AA
LEVER
1
3 N210103096AE
LEVER
1
4 N210103097AB
PLATE
1
5 N210091110AA
SHAFT
1
6 N210091266AB
WASHER
1
7 N210117347AA
WASHER
1
8 N210117346AB
PLATE
1
9 N210105333AD
GUIDE
1
10 N210103100AB
BRACKET
1
11 KXFB00JJA01
SWITCH(400mm)
1
12 N610076513AA
CAM-FOLLOWER
1
13 N510036568AA CF-SFU-12B
BUSH
1
14 N510037242AA LFF-2010
BUSH
1
15 N510013369AA LFF-2015
WASHER
1
16 N510037241AA LFW-2015
PIN
1
17 N510020590AA MMS3-10
DOWEL-PIN
1
19 N510038675AA 87MST8-30
SPRING
1
20 N510033553AA 6796
CYLINDER
1
21 N510061079AA CDQ2D63-135DCZ-XB10
ROD-END
1
22 N510014419AA SAJK10C
BOLT
1
23 N510037244AA 87MSB10-20
SPACER
10
24 N510037246AA ASF-850E
POST
1
25 N510037245AA 87ETKR8-50
SPEED-CONTROLLER
2
26 N510040089AA AS2201F-02-06S-8-X250
BOLT
2
27 N510017516AA
SSS 003 Hexagon socket button head screw M4X10-10.9 A2J (Trivalent)
BOLT
21
28 N510017569AA
SSS 003 Hexagon socket button head screw M8X10-10.9 A2J (Trivalent)
SPACER
1
30 N510042412AA 3382330-60080
PIN
1
31 N510020607AA MMS5-10
PIN
1
32 N510027277AA MMST8-15
O146
--
( KN610112809AA-09-2 )
