19-C 全 体 カバー: NPM -D2 W hole Cover:NP M_D2 パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N6 10 156 14 3A B ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S61 ( KN610156143AB-03-3 )
Ref
No.
Remarks
R
1
Q'ty
19-B
全
体
カバー:NPM-D2
Whole Cover:NPM_D2
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610156143AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
1 N210153539AF
FRAME
1
2 N210153540AF
COVER
2
3 N210153552AC
COVER
2
4 N210153553AC
COLLAR
2
5 N210156011AA
COLLAR
4
6 N210157939AA
WASHER
4
7 N210157945AA
BRACKET
4
8 N210153557AA
BRACKET
2
9 N210134125AA
BRACKET
4
10 N210092152AC
LEVER
1
11 N210153559AC
LEVER
1
12 N210153560AC
BRACKET
2
13 N210162762AA
COVER
2
14 N210162763AA
COVER
2
15 N210161630AA
PLATE
2
16 N610136795AA
COVER
2
17 N610136781AA
COVER
2
18 N610136782AB
COVER
2
19 N610136783AA
COVER
4
20 N610136784AA
HINGE
4
21 N610130352AB
SWITCH
2
22 N510034226AA
S
D4NH-9BBC
GAS-SPRING
4
23 N510046058AA
S
KMF100-20M
BOLT
4
24 N510020762AA MMSB10-10
SPACER
2
25 N510017092AA CB-312E
WASHER
2
26 N510018472AA
Iron round plain washer3X10X1.0(chromeite) A2J (Trivalent)
E-RING
4
27 KXF0AG0AA00 B-1024-4
BOLT
4
28 N510001582AA SRBS-M4X30
BOLT
2
29 N510028457AA SRBS-M3X16
MAGNET
4
30 N986MC159 MC-159
SCREW
8
31 N510018158AA
Cross recessed Countersunk head machine screw M3X6-4.8 A2J (Trivalent)
SPACER
2
32 N510030906AA CB-350E
BOLT
2
33 N510017336AA
Hexagon socket head cap screw M3X60-10.9 A2J (Trivalent)
CABLE-SUPPORT
2
34 N510048516AA FT3
WASHER
8
35 N510048767AA PSW-0409-08
BUSH
8
36 N510056255AA PE4050-9130
PULL
2
37 KXF0DX62A00 AP-829-2
BOLT
4
38 N510032425AA MMSB10-30
BOLT
4
39 N510063092AA
EH0410 Trivalent Chromate(MEC thread lock:ThreeBond 2430)
SCREW
48
40 N510049926AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent)
SPACER
2
41 N510030217AA CB-305E
SCREW
10
42 N510049925AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
SPACER
4
43 N510021007AA CF-408E
S60
--
( KN610156143AB-03-2 )
19-C
全
体
カバー:NPM-D2
Whole Cover:NPM_D2
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610156143AB
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S61
( KN610156143AB-03-3 )
Ref
No.
Remarks
R
1
Q'ty
19-C
全
体
カバー:NPM-D2
Whole Cover:NPM_D2
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610156143AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
GUIDE
1
1 N210185609AA
BLOCK
1
2 N210139464AA
BLOCK
2
3 N210110023AA
BLOCK
1
4 N210139467AA
FRAME
1
5 N210146149AC
BRACKET
1
6 N210157378AA
BRACKET
2
7 N210157379AA
BRACKET
2
8 N210110281AB
NUT-PLATE
1
9 N210134097AA
GUIDE
1
10 N210183846AB
BRACKET
1
11 N210157380AA
SPACER
7
12 N510016347AA 3382330-40030
S62
--
( KN610156143AB-03-3 )
