Part 3 Maintenance

1. Cleaning................................................................(Edition 1.0) ......3-1-1

1.1 Emptying the Waste Tape Box (Every 8 Hours)..............................................3-1-1

1.2 Cleaning the Nozzle Interior (Every Week)......................................................3-1-2

1.3 Emptying the Reject Parts Box (Everyday)......................................................3-1-3

1.4 Cleaning the Regulator Filter (Every Month) ...................................................3-1-4

1.5 Cleaning the Gauge Chip Part (Every Week)..................................................3-1-5

1.6 Cleaning the Vacuum Pump Filter (Every Week)............................................3-1-6

1.7 Cleaning the Machine Interior (Every Week)..................................................3-1-7

2. Lubrication.............................................................(Edition 1.0) ......3-2-1

Precautions During Lubrication..............................................................................3-2-1

Types of Lubricants ...............................................................................................3-2-1

Grease Gun Kit......................................................................................................3-2-2

Lubrication Instructions..........................................................................................3-2-3

2.1 Lubricating the XY-robot (Y-axis only).............................................................3-2-4

2.2 Lubricating the Placing Head...........................................................................3-2-5

2.3 Lubricating the Conveyor.................................................................................3-2-6

2.4 Lubricating the Tape Cutter.............................................................................3-2-7

2.5 Lubricating the F, G-Axis.................................................................................3-2-8

2.6 Lubrication Checklist........................................................................................3-2-9

3. Replacing Consumable Parts................................(Edition 1.0) ......3-3-1

3.1 Replacing the Strobe Light ..............................................................................3-3-1

3.2 Replacing the Conveyor Belt...........................................................................3-3-2

3.3 Replacing the Filter of the Vacuum Generator Used for Gauge Chip

Part Pickup (Every Year) .................................................................................3-3-3

3.4 Replacing the Mark Camera Lamp..................................................................3-3-4

Part 4 Setup

1. Leveling the Machine............................................(Edition 1.0) ......4-1-1

2. Connecting the Air.................................................(Edition 1.0) ......4-2-1

3. Electrical Power Supply & Transformer Wiring .....(Edition 1.0) ......4-3-1

4. Connecting the Data Transmission Cable (RS-232C)(Edition 1.0)..4-4-1

5. Connecting the Data Transmission Cable (Ethernet)(Edition 1.2)...4-5-1

Supplementary Information

1. Noise Levels..........................................................(Edition 1.1)......A-1-1

Contents – List of Current Pages

Edition 1.2 vi XP-141E Mechanical

Safety Guidelines

Fuji machines are designed and produced with safety as

one of our main considerations. However, even a

perfectly designed machine can be damaged, or someone

can still be injured if the user does not follow the safety

rules. It is the responsibility of the user to make sure all

safety rules are followed during operation and

maintenance.

Be sure to read these safety rules before operating the

machine. Keep this manual close to hand when

operating the machine.

1. About Symbols

To avoid injury to persons and damage to the machine, Fuji employs a number of messages

and symbols that are used in manuals and on the machines. Be sure you understand the

meanings of these symbols before reading the manual.

Hazard warnings are divided into the following three classes:

Safety Guidelines

Edition 1.2 1 XP-141E Mechanical

DANGER

The hazard or unsafe practice will cause severe injury or

death.

WARNING

The hazard or unsafe practice may cause severe injury or

death.

CAUTION

The hazard or unsafe practice may lead to personal injury

or damage to the machine.

To distinguish the type of hazard, the following symbols are used in combination with the

ones above.

Hazard Alert

A triangle is used to draw your attention to a hazard. The symbol inside the

triangle indicates the nature of the hazard (in this case electrical shock).

Prohibition

A circle with a diagonal line inside is used to draw your attention to an

operation that is prohibited. The symbol inside the circle indicates the nature

of the operation (in this case disassembly).

A circle with an exclamation mark is used to draw your attention to a

mandatory action. In other words, you are required to carefully carry out the

given instructions.
