Resupply solder paste, glue and parts while the machine is in manual mode. ● Never resupply solder, glue or parts during automatic operation unless instructed otherwise. Body parts or clothing may be caught in the machin…
Safety Guidelines
Edition 1.2 3 XP-141E Mechanical
Check that there is nobody inside the machine when
working on the machine with two persons or more.
● Verify that nobody is within or near the machine before operating
the machine. Operating the machine may cause injury to the
person who is carrying out maintenance.
[Example]
If one person moves the device table while another person is
exchanging a feeder, the latter may be injured.
Do not close the fence when someone is inside the
fence.
● When the fence is opened, it is safe to approach the machine.
Closing the fence, however, will put anybody working inside the
fence in immediate danger when the RESET or START button is
pressed. Be sure to leave the fence open when anyone is inside
the fence.
Do not approach a machine that has stopped moving.
● There are times during automatic operation when the machine may
appear to have stopped while it is waiting for a board, waiting for the
next machine, reading marks, transmitting data, etc. In such cases,
once certain conditions are fulfilled, the machine will begin moving
again automatically, so care should be taken. Only approach the
machine after the EMERGENCY STOP button has been pressed.
When the message "Ready" displays at the machine display, the
machine will begin to move once certain conditions are fulfilled.
● Keep in mind that the machine will begin to move regardless of
whether these conditions are fulfilled intentionally or inadvertently.
WARNING
Resupply solder paste, glue and parts while the
machine is in manual mode.
● Never resupply solder, glue or parts during automatic operation
unless instructed otherwise. Body parts or clothing may be caught
in the machine causing personal injury.
Do not place hands near the main conveyor.
● Hands or other body parts may be caught in the machine.
Always turn the 200 V power supply off when cleaning
or lubricating the machine.
● When the 200 V power supply to the machine is turned on, the
servo amps will be activated. In this condition the machine may
unexpectedly begin to move.
Do not insert or remove connectors while power is
being supplied to the machine.
● Removing or inserting connectors while power is supplied to the
machine may not only cause damage to the machine, but may also
cause electrical shock.
● Be sure to cut the power to the machine before inserting or
removing connectors.
Stay clear from the machine when it is being lifted.
● Never put hands or feet under the machine when the machine is
being raised by means of a jack or other device for leveling or
transport.
Safety Guidelines
Edition 1.2 4 XP-141E Mechanical
WARNING
Do not look into the conveyor inlet or outlet and do not
open the cover. (Reflow oven)
● Do not look into the conveyor inlet or outlet and do not open the
cover.
[Example]
The UV light on the reflow oven may damage eyesight or result in
burns.
Exchange the halogen lamp only after it has cooled
down.
● When turned on, halogen lamps will reach high temperatures,
resulting in skin burns when touched. To exchange a halogen
lamp, turn off the power and allow the lamp to cool off sufficiently.
Do not wear gloves made of cloth when operating the
machine.
● Rubber gloves will tear when caught by the machine and prevent
hands from being drawn into the machine. Gloves made of cotton
or similarly strong material may cause hands to be drawn into the
machine.
Long hair should be tied back.
● Long hair may get caught in running machines.
Hair should be kept short or tied back so that it does not get caught
in the machine.
Turn off the air supply when carrying out maintenance
on cylinders, valves, and filters.
● Removing cylinders, valves, or filters without turning the air supply
off, may cause parts or particles to be propelled into the eyes.
● Be sure to turn off the air supply when carrying out maintenance on
cylinders, valves, and filters.
Safety Guidelines
Edition 1.2 5 XP-141E Mechanical
WARNING
