Do not look into the conveyor inlet or outlet and do not open the cover . (Reflow oven) ● Do not look into the conveyor inlet or outlet and do not open the cover. [Example] The UV light on the reflow oven may damage eyes…
Resupply solder paste, glue and parts while the
machine is in manual mode.
● Never resupply solder, glue or parts during automatic operation
unless instructed otherwise. Body parts or clothing may be caught
in the machine causing personal injury.
Do not place hands near the main conveyor.
● Hands or other body parts may be caught in the machine.
Always turn the 200 V power supply off when cleaning
or lubricating the machine.
● When the 200 V power supply to the machine is turned on, the
servo amps will be activated. In this condition the machine may
unexpectedly begin to move.
Do not insert or remove connectors while power is
being supplied to the machine.
● Removing or inserting connectors while power is supplied to the
machine may not only cause damage to the machine, but may also
cause electrical shock.
● Be sure to cut the power to the machine before inserting or
removing connectors.
Stay clear from the machine when it is being lifted.
● Never put hands or feet under the machine when the machine is
being raised by means of a jack or other device for leveling or
transport.
Safety Guidelines
Edition 1.2 4 XP-141E Mechanical
WARNING
Do not look into the conveyor inlet or outlet and do not
open the cover. (Reflow oven)
● Do not look into the conveyor inlet or outlet and do not open the
cover.
[Example]
The UV light on the reflow oven may damage eyesight or result in
burns.
Exchange the halogen lamp only after it has cooled
down.
● When turned on, halogen lamps will reach high temperatures,
resulting in skin burns when touched. To exchange a halogen
lamp, turn off the power and allow the lamp to cool off sufficiently.
Do not wear gloves made of cloth when operating the
machine.
● Rubber gloves will tear when caught by the machine and prevent
hands from being drawn into the machine. Gloves made of cotton
or similarly strong material may cause hands to be drawn into the
machine.
Long hair should be tied back.
● Long hair may get caught in running machines.
Hair should be kept short or tied back so that it does not get caught
in the machine.
Turn off the air supply when carrying out maintenance
on cylinders, valves, and filters.
● Removing cylinders, valves, or filters without turning the air supply
off, may cause parts or particles to be propelled into the eyes.
● Be sure to turn off the air supply when carrying out maintenance on
cylinders, valves, and filters.
Safety Guidelines
Edition 1.2 5 XP-141E Mechanical
WARNING
Safety Guidelines
Edition 1.2 6 XP-141E Mechanical
Be sure to wear protective glasses.
● Be sure to wear protective glasses.
[Example]
CP-6, 7 nozzles use springs which may be propelled during
disassembly. Be sure to handle the nozzles carefully to prevent eye
injuries.
Check the machine monitor and the target axes
while manually operating the machine.
● When operating the machine, carefully follow the instructions that
are displayed at the machine display.
● Operating the machine without looking at the machine display may
lead to operating errors or result in damage to the machine or
products.
WARNING
CAUTION
Do not operate the machine after removing or disabling
sensors.
● Removing or disabling sensors will disarm the interlock, leading to
collisions and damage to the machine.
Check the machine display to determine whether
HELPS compatible machines are in the middle of
performing changeover.
● During operation in automatic mode on machines equipped with
automatic changeover equipment, it may be difficult to actually see
automatic changeover taking place from the front of the machine.
When a message appears at the machine display, follow the
instructions that are given.
