5. The EMERGENCY ST OP Button In the event of an emergency, press any of the red EMERGENCY STOP buttons located on the machine at the positions indicated in the figure below. XP1MO002 Front side Rear side Safety Guidelin…
4. Safety Labels
To warn the operator of hazards, safety labels are attached to the machine at the
positions indicated in the figure below.
Familiarize yourself with each label and its message before operating the machine.
1
8
8
4
1
4
1
6
9
7
5
1
1
1
1
2
2
3
3
3
3
7
9
XP1MO001b
1
1
1
2
3
4
5
6
7
8
9
Never insert your hand
inside an operating machine.
Moving parts may cause injury.
DANGER
ETHRNET
NETWORK
FERRITE CORE (ACCESARY)
ZCAT3035-1330, TDK
When connecting the network
cable, attach the ferrite
core as shown in the figure.
Stop the machine and press this button at least
once a day to test the machine's safety swiches.
<
CAUTION
>
Tighten the monitor fixing screws to
a torque of 8kg·cm Over tightening the
screws may damage the liquid crystal
display.
+
VH1
-
VH1TRIG*
<CAUTION>
Connect as shown above.
The lamp will not illuminate
property if not connected
correctly.
DANGER
Be sure to turn off the power
and wait five minutes before
replacing the flash lamp.
Front side
Rear Side
[High Voltage]
[Caution]
Safety Guidelines
Edition 1.2 9 XP-141E Mechanical
5. The EMERGENCY STOP Button
In the event of an emergency, press any of the red EMERGENCY STOP buttons located
on the machine at the positions indicated in the figure below.
XP1MO002
Front side
Rear side
Safety Guidelines
Edition 1.2 10 XP-141E Mechanical
Part 1
The Machine
