Notes: About This Manual Edition 1.2 iv XP-141E Mechanical
Body
The information needed to understand the workings of the machine and how to perform
maintenance is explained using text and illustrations.
Page number
A three digit hyphenated number appears in the footer on each page. The first digit of
each page number indicates the part number, the second digit indicates the chapter
number within the part, and the final digit is the sequential page number within that
chapter. Page 1-2-1, for example, indicates that this is the first page in the second chapter
of part 1.
Manual name
The name of the manual that appears on the cover is also shown in the footer on each
page.
Edition number
The edition number is updated each time the manual is revised, with the number
reflecting the scale of changes that were made.
Minor revision: Minor changes are reflected in the part of the edition number after
the decimal point, for example, a change from edition 1.0 to 1.1. This
change is made on the revised pages only, and these pages can be
downloaded as required from Fuji's website.
Major revision: If major changes are made, the edition number is increased by one,
for example, a change from edition 1.0 to 2.0. This change is made on
all pages.
About This Manual
Edition 1.2 iii XP-141E Mechanical
Notes:
About This Manual
Edition 1.2 iv XP-141E Mechanical
Contents –
List of Current Pages
Safety Guidelines......................................................(Edition 1.2)
1. About Symbols.......................................................................................1
2. Safety Rules for All Machine Types.......................................................2
3. Safety Rules for Individual Machine Types............................................7
XP-1 Series Machines..................................................................................................7
4. Safety Labels.........................................................................................9
5. The EMERGENCY STOP Button........................................................10
Part 1 The Machine
1. Machine Overview.................................................(Edition 1.0) ......1-1-1
Machine Movement During Operation...................................................................1-1-1
2. Machine Components...........................................(Edition 1.2) ......1-2-1
General View.........................................................................................................1-2-1
Inside the Machine.................................................................................................1-2-2
MFU-X10E.............................................................................................................1-2-3
3. Functions of Each Part..........................................(Edition 1.0) ......1-3-1
Parts Mounting System..........................................................................................1-3-1
Parts Supply System .............................................................................................1-3-1
Vision System........................................................................................................1-3-2
Board Conveyance................................................................................................1-3-2
Electrical Control System.......................................................................................1-3-2
Part 2 Basic Operation
1. Changing the Conveyor Width..............................(Edition 1.0) ......2-1-1
2. Changing the Position of the Back-up Pins...........(Edition 1.0) ......2-2-1
Contents – List of Current Pages
Edition 1.2 v XP-141E Mechanical
