MACHINE CONTROL
CAN BUS
7.40 Technical Reference Manual Chapter Issue 8 Oct 06
N3SK9
N3SK10
N3SK11
N3SK12
Pin No. Signal Pin No. Signal
1 +12V 3 0V
2 Drip Tray Retracted
1
3Way Trident Connector
Pin No. Signal Pin No. Signal
1+12V 4+12V
2 Cartridge Vertical 5 Cartridge Horizontal
30V 60V
4
1
6Way Trident Connector
Pin No. Signal Pin No. Signal
1 +12V 3 0V
2 Cartridge Empty/Paste Level
1
3Way Trident Connector
Pin No. Signal Pin No. Signal
1 +12V 3 0V
2 Spare Input
1
3Way Trident Connector
MACHINE CONTROL
CAN BUS
Chapter Issue 8 Oct 06 Technical Reference Manual 7.41
N3SK13
N3SK14
N3SK15
Pin No. Signal Pin No. Signal
1 24V US 6 ProFlow Pressure Demand
20V 724V US
3 Spare Output 8 0V
4 12V 9 ProFlow Pressure Monitor
50V
9Way DType Socket
1
6
Pin No. Signal Pin No. Signal
1+12V 30V
2 Ball Escape (Ball Bumping only)
1
3Way Trident Connector
Pin No. Signal Pin No. Signal
1I DAT 65.5V
20V 7I CLOCK
3DAT_INT 8IO_B
4 VPP 9 0V
5IO_C
9Way DType Socket
1
6
MACHINE CONTROL
CAN BUS
7.42 Technical Reference Manual Chapter Issue 8 Oct 06
N3SK16
N3SK17
Pin No. Signal Pin No. Signal
10V 6N/C
2N/C 7Bridge O/P +
3N/C 8Bridge O/P -
4N/C 9N/C
5+4.1V
9Way DType Socket
1
6
Pin No. Signal Pin No. Signal
1 +12V 6 0V
2 0V 7 ProFlow Cassette Low
3 Paste Level 8 0V
4+12V 9+12V
5 ProFlow Fitted
9Way DType Socket
1
6
