尊敬的用户 Dear users ： 感谢您使用和 田古德精密机 械设备有限公 司生产的全自 动视觉印刷机 。和田古德精 密机械设 备有限公司秉 持“设计制造 客 户满意产品” 的理念，公司 积极进取，科 学管理，始终 坚持以高效的 运作、世 界同步的技术 、国际认证的 品质、精益求 精的精 神服务于客户 ，愿与客户建 立忠实的合作 伙伴关系，共 同发展壮大。 Thank you for using the full-au tomati…
尊敬的用户 Dear users：
感谢您使用和田古德精密机械设备有限公司生产的全自动视觉印刷机。和田古德精密机械设备有限公司秉持“设计制造客
户满意产品”的理念，公司积极进取，科学管理，始终坚持以高效的运作、世界同步的技术、国际认证的品质、精益求精的精
神服务于客户，愿与客户建立忠实的合作伙伴关系，共同发展壮大。
Thank you for using the full-automatic visual printing machine produced by Hetiangude Precision Machinery Equipment
Co., Ltd. Based on the philosophy of “designing and manufacturing the satisfactory products”, Hetiangude Precision
Machinery Equipment Co., Ltd is always positive and committed to scientific management, and serving customers with
efficient production, world synchronous technology,internationally certified quality and striving-for-perfection spirit; the
company is willing to establish the faithful partnership with customers for the common development.
全自动视觉印刷机是本公司最新开发设计的新一代全自动印刷机，具有机器视觉自动识别功能，采用高精度伺服
（Servo）驱动系统，实现快速而准确的对准定位，精确度可达± 0.01 毫米，独立的清洗系统，印刷周期小于8 秒，确保了高
质量的焊膏印刷和高的生产效率，可完美地印刷0.3mm Pitch超细间距焊盘。整机采用计算机控制，具有 Windows 7 " 视窗 "
操作界面和丰富的软件功能，可由软件设定印刷高度，刮板压力以及印刷行程，速度, 网板自动清洗周期数等印刷参数，保证
印刷品质的稳定，可极大地方便用户的使用。
Full-automatic visual printing machine is a new generation of full-automatic printing machine developed and designed
by our company; it is equipped with the Machine Vision automatic identification function and high-precision Servo driving
system, so as to achieve the fast and accurate alignment and positioning with the available precision of ± 0.01 mm and the
independent cleaning system with the printing cycle less than 8 seconds; so the high-quality solder paste printing and high
production efficiency is guaranteed, and the bonding pad with an ultra-fine pitch of 0.3mm can be produced perfectly. The
machine is controlled by computer with Window 7 “windowing” operation interface and abundant software function; the
printing parameters, including the printing height, squeegee pressure, printing stroke and speed, the number of automatic
cleaning cycles, can be set by software, so as to guarantee the stable printing quality and great convenience for the users.
再次感谢您选购和田古德精密机械！
Thanks for purchasing Hetiangude Precision Machinery again!
特别声明（
Important clause
）
:本说明书是和田古德印刷机通用说明书，软件操作界面是大体相同的，所以
操作说明可以通用，软件和硬件配置如果有升级，认实际机器为准，部分功能参数会有所区别，如有疑问请联系我们
This manual is a universal manual for Hetian Good Printing Machine. The software operation interface is generally
the same, so the operation instructions can be used interchangeably. If there are upgrades to the software and
hardware configuration, please refer to the actual machine. Some functional parameters may differ. If you have any
questions, please contact us
- 3
目 录
Content
第一章 系统描述 页码
Chapter 1 System description Page
1.1 功能特性·························· 9
Function
1.2 技术参数·························· 11
Parameters
1.3 外形尺寸·························· 15
Overall dimension
1.4 系统主要组成部分······················ 15
System main sections
1.5 工作原理·························· 19
Working principles
第二章 设备吊装、安装与调试····················20
Chapter 2 Equipment installation and debugging
2.1 吊装安全作业························ 20
Safe lifting operation
2.2 开箱···························· 28
Open the equipment
2.3 操作环境·························· 29
Operating environment
2.4 设备安置及高度调整····················· 30
Equipment location and height adjustment
2.5 电源气源·························· 30
Power and air power
2.6 工控机控制系统安装····················· 31
Installation of the industrial computer control system
2.7软件安装·························· 32
Software installation
第三章 生产工作流程······················· 34
Chapter 3 Production working flow
