MACHINE CONTROL M36 MACHINE CONTROL ENCLOSURE 7.26 Technical Reference Manu al Chapter Issue 3 Jan 08 M36SK21 (Squeegee Motors) M36SK22 (Moving Rail Motor) M36SK23 (X Forward Actuator) Pin No. Signal Pin No. Signal 1 CH1…
MACHINE CONTROL
M36 MACHINE CONTROL ENCLOSURE
Chapter Issue 3 Jan 08 Technical Reference Manual 7.25
M36SK19 (I/O Rear Right)
M36SK20 (Low Current DC In)
Pin No. Signal Pin No. Signal
1 +12V 9 0V
2 Spare Input 10 +12V
3 0V 11 Camera Y Home
(linear drive machines only)
4+12V 120V
5 Spare Input 13 N/C
6 0V 14 Spare Output
7+12V 150V
8 Moving Rail Home
Pin No. Signal Pin No. Signal
1 -12V 9 24V SW
2 -12V 10 24V SW
3 +5.5V 11 0V Return
4 +5.5V 12 0V Return
5 24V US 13 N/C
6 24V US 14 N/C
7 0V Return 15 N/C
80V Return
15 Way D Type Socket
9
1
15 Way D Type Plug
1
9
MACHINE CONTROL
M36 MACHINE CONTROL ENCLOSURE
7.26 Technical Reference Manual Chapter Issue 3 Jan 08
M36SK21 (Squeegee Motors)
M36SK22 (Moving Rail Motor)
M36SK23 (X Forward Actuator)
Pin No. Signal Pin No. Signal
1 CH1 B- 6 CH2 A-
2 CH2 B- 7 CH1 A+
3 CH1 B+ 8 CH2 A+
4CH2 B+ 9N/C
5CH1 A-
Pin No. Signal Pin No. Signal
1CH2 B- 6N/C
2N/C 7CH2 A+
3CH2 B+ 8N/C
4N/C 9N/C
5CH2 A-
Pin No. Signal Pin No. Signal
1CH1 B- 6N/C
2N/C 7CH1 A+
3CH1 B+ 8N/C
4N/C 9N/C
5CH1 A-
9 Way D Type Socket
1
6
9 Way D Type Socket
1
6
9 Way D Type Socket
1
6
MACHINE CONTROL
M36 MACHINE CONTROL ENCLOSURE
Chapter Issue 3 Jan 08 Technical Reference Manual 7.27
M36SK24 (X Rear Actuator)
M36SK25 (Y Actuator)
M36PL26 (High Current DC In)
Pin No. Signal Pin No. Signal
1CH2 B- 6N/C
2N/C 7CH2 A+
3CH2 B+ 8N/C
4N/C 9N/C
5CH2 A-
Pin No. Signal Pin No. Signal
1CH1 B- 6N/C
2N/C 7CH1 A+
3CH1 B+ 8N/C
4N/C 9N/C
5CH1 A-
Pin No. Signal Pin No. Signal
1 +12V 5 +24V US
20V Return 60V Return
3 +24V SW (Belt Motors) 7 +24V SW (Stepper Motors)
40V Return 80V Return
9 Way D Type Socket
1
6
9 Way D Type Socket
1
6
8 Way Power D Type Plug
1
