4 3 (CHECK2 R) 3 (CHECK1 R) 1 1 10 3 (CHECK4 R) 3 (CHECK5 R) 3 (CHECK5 F) 3 (CHECK4 F) 3 (CHECK3 R) 7 3 (CHECK3 F) 3 (CHECK2 F) 3 (CHECK1 F) 4 1 1 If a flow direction of the PCB c hanges, the installation order of CHECK …
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 90990-33J024 BOLT,STOPPER 4 / × 39
2 KHN-M9C00-00X BALL SCREW UR 1 / × 40
3 KHN-M2A06-00X COLLAR UR BS 1 / × 41
4 KW3-M2208-00X SUPPORT UNIT 1 / × 42
5 90933-01J000 BEARING 1 /
×
43
6 99009-10400 CIRCLIP 1 /
×
44
7 KHN-M2A07-02X COVER,BS 1 /
×
45
8
KHN-M2A0A-00X
COUPLING 1
/
×
46
9 KHN-M2A0B-00X
DUCT,CABLE
1 B
×
47
10 KHN-M2A0C-00X TAPE,OUTSIDE 1 / × 48
11 KHN-M2A0D-00X TAPE,INSIDE 1 / × 49
12 KHN-M2A0E-00X TAPE,MIDDLE 1 /
×
50
13 KHN-M291C-00X T2 DUCT BRACKET 1 2 /
×
51
14 90990-01J032 BOLT,HEX.SOCKET HEAD 8 /
×
52
15 KHN-M291D-00X T2 DUCT BRACKET 2 2 / × 53
16 KHN-M2A0F-00X BRACKET,DOG 1 / × 54
17
KHN-M2A0G-00X DOG,ORIGIN 1 / × 55
18 KHN-M2A0H-00X DOG,2ND LIMIT 1 / × 56
19 KHN-M2A0J-00X DOG UR 1 /
×
57
20 91312-04018 BOLT HEX.SOCKET HEAD 4
M4X18
/
×
58
21 91312-04014 BOLT HEX.SOCKET HEAD 38
M4X14
/ × 59
22 91312-04010 BOLT HEX.SOCKET HEAD 4
M4X10
/ × 60
23 91312-03006 BOLT HEX.SOCKET HEAD 4
M3X6
/ × 61
24 98902-04008 SCREW,BINDING HEAD 4 / × 62
25 98902-03005 SCREW,BINDING HEAD 4 /
×
63
26 92902-04200 WASHER,PLAIN 2 /
×
64
27 92902-03200 WASHER,PLAIN 4 /
×
65
28 90K63-311355 AC SERVO MOTOR 1 <UR> B × 66
29 90K63-311354 AC SERVO MOTOR 1 <UL> B × 67
30 91312-04012 BOLT HEX.SOCKET HEAD 4 68
31 KHN-M652B-40X SENSOR , ULR OT 2
E2S-W22B 2nd Limit
B × 69
32 KHN-M652A-10X SENSOR , ULR ORG 2
E2S-W22 Origin
B × 70
33 KHN-M9511-00X BRACKET,SENSOR 1 / × 71
34 91312-04008 BOLT HEX.SOCKET HEAD 4
M4X8
72
35 98902-03008 SCREW,BINDING HEAD 3 73
36 KHN-M2A0K-01X PLATE,SPRING 1 74
37 75
38 76
KHN-080911
3
5
UR / L-axis
Moving-axis
4
3 (CHECK2 R)
3 (CHECK1 R)
1
1
10
3 (CHECK4 R)
3 (CHECK5 R)
3 (CHECK5 F)
3 (CHECK4 F)
3 (CHECK3 R)
7
3 (CHECK3 F)
3 (CHECK2 F)
3 (CHECK1 F)
4
1
1
If a flow direction of the PCB changes,
the installation order of CHECK No. changes a half turn.
PCB flow
2
11
6
6
9
13
5
11
8
12
KHN-080911
3
6
Transfer
Moving-axis
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KHN-M2993-A0X CYLINDER 1 ASSY
4
B × 26
2
KHN-M653B-10X CYLINDER,CLAW1 F
1 CHECK 1F
B × 27
KHN-M653B-20X CYLINDER,CLAW5 F
1 CHECK 5F
B × 28
KHN-M653B-30X CYLINDER,CLAW1 R
1 CHECK 1R
B × 29
KHN-M653B-40X CYLINDER,CLAW5 R
1 CHECK 5R
B × 30
3 KHN-M2970-00X CLAW ASSY
10
B × 31
4 KHN-M2975-A0X CYLINDER 2 ASSY
2
B × 32
5
KHN-M653C-10X CYLINDER,CLAW2-4 F
1 CHECK 4F
B
×
33
KHN-M653C-20X CYLINDER,CLAW2-4 R
1 CHECK 2R
B
×
34
6 KHN-M2999-00X SPEED CONTROLLER
2
B
×
35
7
KHN-M653D-10X SENSOR , B. CHECK 1F
1
CHECK 1F B
×
36
KHN-M653D-20X SENSOR , B. CHECK 2F
1
CHECK 2F B × 37
KHN-M653D-30X SENSOR , B. CHECK 3F
1
CHECK 3F B × 38
KHN-M653D-40X SENSOR , B. CHECK 4F
1
CHECK 4F B × 39
KHN-M653D-50X SENSOR , B. CHECK 5F
1
CHECK 5F B × 40
KHN-M653D-60X SENSOR , B. CHECK 1R
1
CHECK 1R B
×
41
KHN-M653D-70X SENSOR , B. CHECK 2R
1
CHECK 2R B
×
42
KHN-M653D-80X SENSOR , B. CHECK 3R
1
CHECK 3R B
×
43
KHN-M653D-90X SENSOR , B. CHECK 4R
1
CHECK 4R B × 44
KHN-M653D-A0X SENSOR , B. CHECK 5R
1
CHECK 5R B × 45
8 91312-03014 BOLT HEX.SOCKET HEAD
4 M3X14
46
9 91312-04016 BOLT HEX.SOCKET HEAD
4 M4X16
47
10 91317-03006 BOLT HEX.SOCKET HEAD
1 M3X6
48
11 91380-04010 BOLT HEX.SOCKET HEAD
4 M4X10
49
12 90K63-001257 AC SERVO MOTOR
1
B × 50
13 90K63-311E56 AC SERVO MOTOR
1
B × 51
14 52
15 53
16 54
17 55
18 56
19 57
20 58
21 59
22 60
23 61
24 62
25 63
KHN-1201
3
6
Transfer
Moving-axis
