YSM20R_KMK_pl - 第139页
16 17 19 17 15 29 4 28 17 3 3 24 23 24 21 3 17 3 30 17 2 31 27 32 16 3 4 3 9 9 8 17 8 9 5 7 26 6 9 10 9 8 9 20 13 18 4 14 25 1 12 11 22 16 17 19 17 15 29 4 28 17 3 3 24 23 24 21 3 17 3 30 17 2 31 27 32 16 3 4 3 9 9 8 17 …
27
15
17
28
13
22
26
26
31
21
14
1
36
18
19
1
20
12
30
29
3
30
29
16
26
9,10
11
6
24
5
32
4
8
2,35
7
32
8
33
32
25
25
23
25
32
32
34
27
15
17
28
13
22
26
26
31
21
14
1
36
18
19
1
20
12
30
29
3
30
29
16
26
9,10
11
6
24
5
32
4
8
2,35
7
32
8
33
32
25
25
23
25
32
32
34
Controller
Controller
KMK-1803
15-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KJJ-M412B-00
CLAMP 2
4
2
KKE-M4141-00
DUMMY PANEL SYS
1
3
KLA-M4250-01
BACKPLANE BOARD ASSY
1
4
KLA-M441H-20
VISION BOARD ASSY
1
VISION1
5
KLW-M4530-10
REMOTE IF BOARD ASSY
1
6
KLA-M5303-01
SW POWER DC12
1
VISION2
7
KLA-M5303-10
SW POWER DC5
1
8
KLA-M5840-04
SERVO BOARD ASSY
2
9
KLR-M4111-00
PANEL,DUMMY
1
10
KLA-M5840-16
SERVO BOARD ASSY
1
sATS
11
KLA-M5840-36
SERVO BOARD ASSY
1
12
KLV-M4131-00
BASE,C/R BOX
1
13
KLV-M4132-00
BRKT.,FAN
1
14
KLV-M4133-01
GUIDE,FLOW 2
1
15
KLV-M4134-00
COVER,FILTER 1
1
16
KLV-M4135-00
COVER,FILTER 2
1
17
KLV-M4136-00
FILTER
1
18
KLW-M4186-00
FAN MOTOR ASSY
1
FAN3
19
KLW-M4186-10
FAN MOTOR ASSY
1
FAN4
20
KLW-M4186-20
FAN MOTOR ASSY
1
FAN5
21
KLW-M53L6-00
FAN MOTOR ASSY.
1
FAN2
22
KLW-M53M4-00
FAN MOTOR ASSY.
1
FAN6,7
23
KLW-M5880-00
CONVERTER BOARD ASSY
1
24
KMG-M4209-20
SYSTEM UNIT ASSY
1
25
90166-12JA10
SCREW, PAN HEAD
4
26
91312-04006
BOLT,HEX.SOCKET HEAD
6
27
91312-04030
BOLT,HEX.SOCKET HEAD
4
28
91312-04040
BOLT,HEX.SOCKET HEAD
4
29
91312-05012
BOLT,HEX.SOCKET HEAD
5
30
92902-05200
WASHER, PLAIN
5
31
97602-04306
SCREW,PAN HEAD W/W
2
32
97602-04308
SCREW,PAN HEAD W/W
12
33
KMK-M445E-00
CAP1,25000uF
1
34
KLA-M4255-10
FLASH DISK 4G
1
35
KLA-M441H-20
VISION BOARD ASSY
1
COPLA
36
KLW-M4510-00
MOTHER BOARD ASSY
1
37
30-31
1
2-13
42
35
38
34
38
14-29
33
32
39-41
36
37
30-31
1
2-13
42
35
38
34
38
14-29
33
32
39-41
36
Exterior,etc
Exterior,etc
KMK-1803
16-1
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
KLF-M5119-01
TOUCH LCD ASSY
2
2
KMM-M4899-00
SIG.TOWER ASSY
1
1850mm RYG
3
KMM-M4899-10
SIG.TOWER ASSY
1
1900mm RYG
4
KMM-M4899-20
SIG.TOWER ASSY
1
2000mm RYG
5
KMM-M4899-30
SIG.TOWER ASSY
1
2100mm RYG
6
KMM-M4899-40
SIG.TOWER ASSY
1
2200mm RYG
7
KMM-M4899-50
SIG.TOWER ASSY
1
2300mm RYG
8
KMM-M4899-60
SIG.TOWER ASSY
1
1850mm CBG
9
KMM-M4899-70
SIG.TOWER ASSY
1
1900mm CBG
10
KMM-M4899-80
SIG.TOWER ASSY
1
2000mm CBG
11
KMM-M4899-90
SIG.TOWER ASSY
1
2100mm CBG
12
KMM-M4899-A0
SIG.TOWER ASSY
1
2200mm CBG
13
KMM-M4899-B0
SIG.TOWER ASSY
1
2300mm CBG
14
KLW-M65N5-00
HNS,ENG.ACTIVE
1
15
KLW-M65N5-10
HNS,ENG.READY
1
16
KLW-M65N5-20
HNS,ENG.START
1
17
KLW-M65N5-30
HNS,ENG.STOP
1
18
KLW-M65N5-40
HNS,ENG.ERR.CLR.
1
19
KLW-M65N5-50
HNS,ENG.RESET
1
20
KLW-M65N5-60
HNS,ENG.STOP CE
1
CE
21
KLW-M65N5-70
HNS,ENG.ERR.CLR.CE
1
CE
22
KLW-M65N5-00
HNS,CHN.ACTIVE
1
Chinese
23
KLW-M65N5-90
HNS,CHN.READY
1
Chinese
24
KLW-M65N5-A0
HNS,CHN.START
1
Chinese
25
KLW-M65N5-B0
HNS,CHN.STOP YM
1
Chinese
26
KLW-M65N5-C0
HNS,CHN.ERR.CLR.YM
1
Chinese
27
KLW-M65N5-D0
HNS,CHN.RESET
1
Chinese
28
KLW-M65N5-E0
HNS,CHN.STOP CE
1
Chinese_CE
29
KLW-M65N5-F0
HNS,CHN.ERR.CLR.CE
1
Chinese_CE
30
KMM-M4897-A0
ERROR LIGHT ASSY
2
S.T.D
31
KMM-M4897-B0
ERROR LIGHT ASSY
2
CE
32
KLF-M5138-00
SWITCH EMG SET
1
33
KGK-M5381-00
EMG PLATE
1
34
KKE-M6554-00
MAIN SWITCH
1
35
KKX-M8596-A0
PRESSURE GAUGE
2
36
KLF-M4268-10
USB MEMORY ASSY
1
8GB
37
KLF-M4580-00
I/O CONV.BOARD ASSY
1
38
KLW-M65NA-A0
SELECT 1A ASSY
2
39
KLF-M138J-01
BALL CHAIN
1
40
KLF-M138K-00
RING
1
41
KLW-M516A-00
TOUCH PEN
1
42
KLW-M5150-A0
KEYBOAD ASSY.E (O/P)
1
Keyboad only_KLF-M5150-20
16
17
19
17
15
29
4
28
17
3
3
24
23
24
21
3
17
3
30
17
2
31
27
32
16
3
4
3
9
9
8
17
8
9
5
7
26
6
9
10
9
8
9
20
13
18
4
14
25
1
12
11
22
16
17
19
17
15
29
4
28
17
3
3
24
23
24
21
3
17
3
30
17
2
31
27
32
16
3
4
3
9
9
8
17
8
9
5
7
26
6
9
10
9
8
9
20
13
18
4
14
25
1
12
11
22
Exterior,E/L
Exterior,etc
KMK-1803
16-2
NO
Parts_No.
Parts_Name
Q_ty
Remarks
Compati
Revision_No._date
1
90990-11J003
SCREW, PAN HEAD W/W
12
2
91312-04035
BOLT HEX,SOCKET HEAD
4
3
91312-04045
BOLT HEX,SOCKET HEAD
24
4
98902-03006
SCREW BINDING HEAD
16
5
KH1-M6516-01
CIRCUIT PROTECTOR, 1P
1
6
KH4-M6514-01
CIRCUIT PROTECTOR,3P
1
7
KH4-M6515-31
CIRCUIT PROTECTOR,2P
1
8
KHN-M643A-10
TERMINAL, POWER
6
9
KHN-M643E-10
END PLATE
6
10
KHN-M6513-11
CIRCUIT PROTECTOR,1P
3
11
KJX-M6561-00
POWER SUPPLY1
1
12
KKE-M6561-10
POWER SUPPLY 1
1
13
KKX-M6513-00
CIRCUIT PROTECTOR,1P
2
14
KLA-M4506-01
HEAD I/O UNIT ASSY
1
15
KLA-M459X-01
BATT UNIT ASSY
4
16
KLF-M4187-10
FAN GUARD 80MM
2
17
KLF-M4187-20
FAN GUARD 120MM
6
18
KLF-M537F-00
SAFETY RELAY
1
19
KLF-M537G-00
CONTACTOR,1
2
20
KLF-M537G-50
CONTACTOR,1
2
21
KLF-M6511-00
MAIN BREAKER,1
1
22
KLV-M6561-00
POWER SUPPLY 1
1
23
KLW-M643A-00
TERMINAL,POWER
4
24
KLW-M643E-00
END PLATE
2
25
KMK-M5802-49
HEAD SERVO UNIT ASSY
2
26
KMK-M6185-10
FAN MOTOR ASSY
1
27
KMK-M6185-20
FAN MOTOR ASSY
1
28
KMK-M6185-50
FAN MOTOR ASSY
1
29
KMK-M6185-60
FAN MOTOR ASSY
1
30
KMK-M6185-70
FAN MOTOR ASSY
1
31
KMK-M6185-80
FAN MOTOR ASSY
1
32
KMK-M6185-J0
FAN MOTOR ASSY
1
